DS4830 User’s Guide
32
MODULE 0
Register index 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
PO2 00h PO2[7:0]
PO1 01h PO1[7:0]
PO0 02h PO0[7:0]
EIF2 03h IE7 IE6 IE5 IE4 IE3 IE2 IE1 IE0
EIF1 04h IE7 IE6 IE5 IE4 IE3 IE2 IE1 IE0
EIF0 05h IE7 IE6 IE5 IE4 IE3 IE2 IE1 IE0
GTV1 06h GTV1[15:0]
GTCN1 07h - - - GTR MODE CLK_SEL[1:0] GTIE - - - GTIF - GTPS[2:0]
PI2 08h PI2[7:0]
PI1 09h PI1[7:0]
PI0 0Ah PI0[7:0]
GTC1 0Bh GTC1[15:0]
EIE2 0Dh EX7 EX6 EX5 EX4 EX3 EX2 EX1 EX0
EIE1 0Eh EX7 EX6 EX5 EX4 EX3 EX2 EX1 EX0
EIE0 0Fh EX7 EX6 EX5 EX4 EX3 EX2 EX1 EX0
PD2 10h PD2[7:0]
PD1 11h PD1[7:0]
PD0 12h PD0[7:0]
EIES2 13h IT7 IT6 IT5 IT4 IT3 IT2 IT1 IT0
EIES1 14h IT7 IT6 IT5 IT4 IT3 IT2 IT1 IT0
EIES0 15h IT7 IT6 IT5 IT4 IT3 IT2 IT1 IT0
