DS4830 User’s Guide
159
When REGE = 1: This register serves as one of the two register breakpoints. A break occurs when the destination register
address for the executed instruction matches with the specified module and index. The destination module is indicated by
the M[3:0] bits and the register within that module is defined by the r[4:0] bits.
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name - - - - - - - r.4 r.3 r.2 r.1 r.0 M.3 M.2 M.1 M.0
Reset 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Access s s s s s s s s s s s s s s s s
s = special
21.1.1.6 – Breakpoint 5 Register (BP5)
The Breakpoint 5 register is accessible only via background mode read/write commands.
When REGE = 0: This register serves as one of the two data memory address breakpoints. When DME is set in
background mode, the debug engine will monitor the data memory address bus activity while the CPU is executing the
user program. If an address match is detected, a break occurs, allowing the debug engine to take over control of the CPU
and enter debug mode.
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name BP5.15 BP5.14 BP5.13 BP5.12 BP5.11 BP5.10 BP5.9 BP5.8 BP5.7 BP5.6 BP5.5 BP5.4 BP5.3 BP5.2 BP5.1 BP5.0
Reset 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Access s s s s s s s s* s* s* s* s* s** s** s** s**
s = special
When REGE = 1: This register serves as one of the two register breakpoints. The destination module is indicated by the
M[3:0] bits and the register within that module is defined by the r[4:0] bits. A break occurs when two following conditions
are met:

The destination register address for the executed instruction matches with the specified module and index.

The bit pattern written to the destination register matches those bits specified for comparison by the ICDD data
register and ICDA mask register. Only those ICDD data bits with their corresponding ICDA mask bits will be
compared. When all bits in the ICDA register are cleared, Condition 2 becomes a don’t care.
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name - - - - - - - r.4 r.3 r.2 r.1 r.0 M.3 M.2 M.1 M.0
Reset 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Access s s s s s s s s s s s s s s s s
s = special
21.1.2
– Using Breakpoints
All breakpoint registers (BP0-BP5) default to the FFFFh state on power-on reset or when the Test-Logic-Reset TAP state
is entered. The breakpoint registers are accessible only with Background mode read/write commands issued over the
TAP communication link. The breakpoint registers are not read/write accessible to the CPU.
Setting the Debug Mode Enable (DME) bit in the ICDC register to logic 1 enables all six breakpoint registers for
breakpoint match comparison. The state of the Break-On Register Enable (REGE) bit in the ICDC register determines
whether the BP4 and BP5 breakpoints should be used as data memory address breakpoints (REGE = 0) or as register
breakpoints (REGE = 1).
When using the register matching breakpoints, it is important to realize that Debug mode operations (e.g., read data
memory, write data memory, etc.) require use of ICDA and ICDD for passing of information between the host and DS4830
ROM routines. It is advised that these registers be saved and restored or be reconfigured before returning to the
background mode if register breakpoints are to remain enabled.
When a breakpoint match occurs, the debug engine forces a break and the DS4830 enters Debug Mode. If a breakpoint
match occurs on an instruction that activates the PFX register, the break is held off until the prefixed operation completes.
The host can assess whether Debug mode has been entered by monitoring the status bits of the 10-bit word shifted out of
the TDO pin. The status bits will change from the Non-debug (00b) state associated with background mode to the Debug-
Idle (01b) state when Debug Mode is entered. Debug mode can also be manually invoked by host issuance of the 'Debug'
background command.
