DS4830 User’s Guide
183
MOVE Acc, Acc
(Recirculation of active accumulator contents)
XCHN
(Exchange nibbles within each byte of active accumulator)
XCH
(Exchange active accumulator bytes)
The active accumulator may not be the source in any instruction where it is also the implicit destination.
There is an addi
tional notation that can be used to refer to the active accumulator for the instruction “MOVE dst, Acc”. If
the instruction is instead written as “MOVE dst, A[AP]”, the source value is still the active accumulator, but no AP auto-
increment or auto-decrement function will take place, even if this function is enabled. Note that the active accumulator
may not be the destination for the MOVE dst, A[AP] instruction (i.e. MOVE Acc, A[AP] is prohibited).
So, the two instructions
move A[7], Acc
move A[7], A[AP]
are equivalent except that the first instruction triggers auto-inc/dec (if it is enabled), while the second one will never do so.
The Accumulator Pointer Control Register (APC) controls the automatic increment/decrement mode as well as selects the
range of bits (modulo) in the AP register that will be incremented or decremented. There are nine different unique settings
for the APC register, as listed in Table 23-1.
Table 23-1. Accumulator Pointer Control Register Settings
APC.2
(MOD2)
APC.1
(MOD1)
APC.0
(MOD0)
APC.6
(IDS)
APC
Auto Increment / Decrement Setting
0
0
0
0
00h
No auto-increment/decrement (default mode)
0
0
1
0
01h
Increment bit 0 of AP (modulo 2)
0
0
1
1
41h
Decrement bit 0 of AP (modulo 2)
0
1
0
0
02h
Increment bits [1:0] of AP (modulo 4)
0
1
0
1
42h
Decrement bits [1:0] of AP (modulo 4)
0
1
1
0
03h
Increment bits [2:0] of AP (modulo 8)
0
1
1
1
43h
Decrement bits [2:0] of AP (modulo 8)
1
0
0
0
04h
Increment all 4 bits of AP (modulo 16)
1
0
0
1
44h
Decrement all 4 bits of AP (modulo 16)
For the modulo increment or decrement operation, the selected range of bits in AP are incremented or decremented.
However, if these bits roll over or under, they simply wrap around without affecting the remaining bits in the accumulator
pointer. So, the operations can be defined as follows:
Increment modulo 2:
AP = AP[3:1] + ((AP[0] + 1) mod 2)
Decrement modulo 2:
AP = AP[3:1] + ((AP[0]
– 1) mod 2)
Increment modulo 4:
AP = AP[3:2] + ((AP[1:0] + 1) mod 4)
Decrement modulo 4:
AP = AP[3:2] + ((AP[1:0]
– 1) mod 4)
Increment modulo 8:
AP = AP[3] + ((AP[2:0] + 1) mod 8)
Decrement modulo 8:
AP = AP[3] + ((AP[2:0]
– 1) mod 8)
Increment modulo 16:
AP = (AP + 1) mod 16
Decrement modulo 16:
AP = (AP
– 1) mod 16
For this example, assume that all 16 accumulator registers are initially set to zero.
move AP, #02h
; select A[2] as active accumulator
move APC, #02h
; auto-increment AP[1:0] modulo 4
; AP A[0] A[1] A[2] A[3]
; 02 0000 0000 0000 0000
add #01h
; 03 0000 0000 0001 0000
add #02h
; 00 0000 0000 0001 0002
add #03h
; 01 0003 0000 0001 0002
add #04h
; 02 0003 0004 0001 0002
add #05h
; 03 0003 0004 0006 0002
