DS4830 User’s Guide
207
POP dst Pop Word from the Stack
Description:
Pops a single word from the stack (@SP) to the specified dst and decrements the stack pointer
(SP).
Status Flags: S, Z (if dst = Acc or AP or APC)
C, E (if dst = PSF)
Operation: dst  @ SP--
Encoding:
15 0
1ddd dddd 0000 1101
Example(s):
POP GR ; GR  1234h
POP @DP[0] ; @DP[0]  76h (WBS0=0)
; @DP[0]  0876h (WBS0=1)
Stack Data:
xxxxh
1234h  SP (initial)
0876h  SP (after POP GR)
xxxxh  SP (after POP @DP[0])
xxxxh
POPI dst Pop Word from the Stack Enable Interrupts
Description:
Pops a single word from the stack (@SP) to the specified dst and decrements the stack pointer
(SP). Additionally, POPI returns the interrupt logic to a state in which it can acknowledge
additional interrupts.
Status Flags: S, Z (if dst = Acc or AP or APC)
C, E (if dst = PSF)
Operation: dst  @ SP--
INS  0
Encoding:
15 0
1ddd dddd 1000 1101
Example(s):
See POP
PUSH src Push Word to the Stack
Description:
Increments the stack pointer (SP) and pushes a single word specified by src to the stack (@SP).
Status Flags:
None
