DS4830 User’s Guide
37
Note: Some of the DS4830 module and peripheral interrupts sources are shown in the Figure 5-1 interrupt hierarchy
diagram. Please refer the corresponding sections of this user’s guide for more detailed information about all of the
possible interrupts.
5.1 – Servicing Interrupts
For the DS4830 to service an interrupt, interrupts must be enabled globally, modularly, and locally. The Interrupt Global
Enable (IGE) bit is located in the Interrupt Control (IC) register acts as a global interrupt mask. This bit defaults to 0, and it
must be set to 1 before any interrupt takes place.
The local interrupt-enable bit for a particular source is in one of the peripheral registers associated with that peripheral
module, or in a system register for any system interrupt source. Between the global and local enables are intermediate
per-module and system interrupt mask bits. These mask bits reside in the Interrupt Mask system register. By
implementing intermediate per-module masking capability in a single register, interrupt sources spanning multiple
modules can be selectively enabled/disabled in a single instruction. This promotes a simple, fast, and user-definable
interrupt prioritization scheme. The interrupt source-enable hierarchy is illustrated in Figure 5-1 as well as Table 5-1.
Table 5-1. Interrupt Sources and Control Bits
INTERRUPT INTERRUPT FLAG LOCAL ENABLE BIT
MODULE
INTERRUPT
IDENTIFICATIO
N BIT
INTERRUPT
IDENTIFICATION
BIT
MODULE
ENABLE
BIT
External Interrupt P2.0 EIF2.IE0 EIE2.EX0 -
IIR.II0 IMR.IM0
External Interrupt P2.1 EIF2.IE1 EIE2.EX1 -
External Interrupt P2.2 EIF2.IE2 EIE2.EX2 -
External Interrupt P2.3 EIF2.IE3 EIE2.EX3 -
External Interrupt P2.4 EIF2.IE4 EIE2.EX4 -
External Interrupt P2.5 EIF2.IE5 EIE2.EX5 -
External Interrupt P2.6 EIF2.IE6 EIE2.EX6 -
External Interrupt P2.7 EIF2.IE7 EIE2.EX7 -
External Interrupt P1.0 EIF1.IE0 EIE1.EX0 -
External Interrupt P1.1 EIF1.IE1 EIE1.EX1 -
External Interrupt P1.2 EIF1.IE2 EIE1.EX2 -
External Interrupt P1.3 EIF1.IE3 EIE1.EX3 -
External Interrupt P1.4 EIF1.IE4 EIE1.EX4 -
External Interrupt P1.5 EIF1.IE5 EIE1.EX5 -
External Interrupt P1.6 EIF1.IE6 EIE1.EX6 -
External Interrupt P1.7 EIF1.IE7 EIE1.EX7 -
External Interrupt P0.0 EIF0.IE0 EIE0.EX0 -
External Interrupt P0.1 EIF0.IE1 EIE0.EX1 -
External Interrupt P0.2 EIF0.IE2 EIE0.EX2 -
External Interrupt P0.3 EIF0.IE3 EIE0.EX3 -
External Interrupt P0.4 EIF0.IE4 EIE0.EX4 -
External Interrupt P0.5 EIF0.IE5 EIE0.EX5 -
External Interrupt P0.6 EIF0.IE6 EIE0.EX6 -
External Interrupt P0.7 EIF0.IE7 EIE0.EX7 -
Timer1 Interrupt GTCN1.GTIF GTCN1.GTIE -
External Interrupt P6.0 EIF6.IE0 EIE6.EX0 MIIR1.P6_0
IIR.II1 IMR.IM1
External Interrupt P6.1 EIF6.IE1 EIE6.EX1 MIIR1.P6_1
External Interrupt P6.2 EIF6.IE2 EIE6.EX2 MIIR1.P6_2
External Interrupt P6.3 EIF6.IE3 EIE6.EX3 MIIR1.P6_3
External Interrupt P6.4 EIF6.IE4 EIE6.EX4 MIIR1.P6_4
External Interrupt P6.5 EIF6.IE5 EIE6.EX5 MIIR1.P6_5
External Interrupt P6.6 EIF6.IE6 EIE6.EX6 MIIR1.P6_6
Supply Voltage Monitor Interrupt SVM.SVMI SVM.SVMIE MIIR1.SVM
I 2 C Master Start Interrupt I2CST_M.I2CSRI I2CIE_M.I2CSRIE
MIIR1.I2CM
I 2 C Master Transmit Complete Interrupt I2CST_M.I2CTXI I2CIE_M.I2CTXIE
I 2 C Master Receive Ready Interrupt I2CST_M. I2CRXI I2CIE_M.I2CRXIE
I 2 C Master Clock Stretch Interrupt I2CST_M.I2CSTRI I2CIE_M.I2CSTRIE
I 2 C Master Timeout Interrupt I2CST_M.I2CTOI I2CIE_M.I2CTOIE
I 2 C Master NACK Interrupt I2CST_M.I2CNACKI I2CIE_M.I2CNACKIE
I 2 C Master Receiver Overrun Interrupt I2CST_M.I2CROI I2CIE_M.I2CROIE
I 2 C Master Stop Interrupt I2CST_M.I2CSPI I2CIE_M.I2CSPIE
SPI Slave Transfer Complete SPICN_S.SPIC
SPICF_S.ESPII MIIR1.SPI_S SPI Slave Write Collision SPICN_S.WCOL
SPI Slave Receive Overrun SPICN_S.ROVR
I 2 C Slave Stop Interrupt I2CST_S.I2CSRI I2CIE_S.I2CSRIE MIIR2.I2CS IIR.II2 IMR.IM2
