DS4830 User’s Guide
35
MODULE 3
Register index 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
MCNT 00h OF MCW CLD SQU OPCS MSUB MMAC SUS
MA 01h MA[15:0]
MB 02h MB[15:0]
MC2 03h MC2[15:0]
MC1 04h MC1[15:0]
MC0 05h MC0[15:0]
GTV2 06h GTV2[15:0]
GTCN2 07h - - - GTR MODE CLK_SEL[1:0] GTIE - - - GTIF - GTPS[2:0]
MC1R 08h MC1R[15:0]
MC0R 09h MC0R[15:0]
GTC2 0Ah GTC2[15:0]
MODULE 4
Register index 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DACD0 00h - - - - DACD0[11:0]
DACD1 01h - - - - DACD1[11:0]
DACD2 02h - - - - DACD2[11:0]
DACD3 03h - - - - DACD3[11:0]
DACD4 04h - - - - DACD4[11:0]
DACD5 05h - - - - DACD5[11:0]
DACD6 06h - - - - DACD6[11:0]
DACD7 07h - - - - DACD7[11:0]
DACCFG 08h DACCFG7[1:0] DACCFG6[1:0] DACCFG5[1:0] DACCFG4[1:0] DACCFG3[1:0] DACCFG2[1:0] DACCFG1[1:0] DACCFG0[1:0]
MODULE 5
Register index 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
QTDATA 00h QTDATA[15:0] SEE QUICK TRIP FOR DETAILS
QTCN 01h - - - QTEN - - - - RW_LST - - LTHT QTIDX[3:0]
LTIF 02h IF[15:0]
HTIF 03h IF[15:0]
SPIB_M 04h SPIB[15:0]
PWMDATA 05h PWMDATA[15:0] SEE PWM SECTION FOR DETAILS
PWMCN 06h - - - M_EN - - - UPDATE PWM_SEL[3:0] - - REG_SEL[1:0]
PWMSYNC 07h - - - - - - PWMSYNC[9:0]
LTIE 08h IE[15:0]
HTIE 09h IE[15:0]
QTLIST 0Ah - - - - - - - - QTSTART[3:0] QTEND[3:0]
SPICN_M 12h STBY SPIC ROVR WCOL MODF MODFE MSTM SPIEN
SPICF_M 13h ESPII SAS - - - CHR CKPHA CKPOL
SPICK_M 14h SPICK[7:0]
