DS4830 User’s Guide
192
SECTION 24
– INSTRUCTION SET
Table 24-1. Instruction Set Summary
Mnemonic Description 16-bit Instruction
Word
Status Bits
Affected
AP
INC/DEC Notes
L
OG
IC
A
L
OP
E
R
A
T
ION
S
AND src Acc  Acc AND src f001 1010 ssss ssss S, Z Y 1
OR src Acc  Acc OR src f010 1010 ssss ssss S, Z Y 1
XOR src Acc  Acc XOR src f011 1010 ssss ssss S, Z Y 1
CPL Acc  ~Acc 1000 1010 0001 1010 S, Z Y
NEG Acc  ~Acc + 1 1000 1010 1001 1010 S, Z Y
SLA Shift Acc left arithmetically 1000 1010 0010 1010 C, S, Z Y
SLA2 Shift Acc left arithmetically twice 1000 1010 0011 1010 C, S, Z Y
SLA4 Shift Acc left arithmetically four times 1000 1010 0110 1010 C, S, Z Y
RL Rotate Acc left (w/o C) 1000 1010 0100 1010 S Y
RLC Rotate Acc left (through C) 1000 1010 0101 1010 C, S, Z Y
SRA Shift Acc right arithmetically 1000 1010 1111 1010 C, Z Y
SRA2 Shift Acc right arithmetically twice 1000 1010 1110 1010 C, Z Y
SRA4 Shift Acc right arithmetically four times 1000 1010 1011 1010 C, Z Y
SR Shift Acc right (0  msbit) 1000 1010 1010 1010 C, S, Z Y
RR Rotate Acc right (w/o C) 1000 1010 1100 1010 S Y
RRC Rotate Acc right (though C) 1000 1010 1101 1010 C, S, Z Y
B
IT
OP
E
R
A
TI
ON
S
MOVE C, Acc. C  Acc. 1110 1010 bbbb 1010 C
MOVE C, #0 C  0 1101 1010 0000 1010 C
MOVE C, #1 C  1 1101 1010 0001 1010 C
CPL C C  ~C 1101 1010 0010 1010 C
MOVE Acc., C Acc.  C 1111 1010 bbbb 1010 S, Z
AND Acc. C  C AND Acc. 1001 1010 bbbb 1010 C
OR Acc. C  C OR Acc. 1010 1010 bbbb 1010 C
XOR Acc. C  C XOR Acc. 1011 1010 bbbb 1010 C
MOVE dst., #1 dst.  1 1ddd dddd 1bbb 0111 C,E 2
MOVE dst., #0 dst.  0 1ddd dddd 0bbb 0111 C,E 2
MOVE C, src. C  src. fbbb 0111 ssss ssss C
MA
TH
ADD src Acc  Acc + src f100 1010 ssss ssss C, S, Z, OV Y 1
ADDC src Acc  Acc + (src + C) f110 1010 ssss ssss C, S, Z, OV Y 1
SUB src Acc  Acc – src f101 1010 ssss ssss C, S, Z, OV Y 1
SUBB src Acc  Acc – (src + C) f111 1010 ssss ssss C, S, Z, OV Y 1
B
R
A
N
C
H
IN
G
{L/S}JUMP src IP  IP + src or src f000 1100 ssss ssss 6
{L/S}JUMP C, src If C=1, IP  (IP + src) or src f010 1100 ssss ssss 6
{L/S}JUMP NC, src If C=0, IP  (IP + src) or src f110 1100 ssss ssss 6
{L/S}JUMP Z, src If Z=1, IP  (IP + src) or src f001 1100 ssss ssss 6
{L/S}JUMP NZ, src If Z=0, IP  (IP + src) or src f101 1100 ssss ssss 6
{L/S}JUMP E, src If E=1, IP  (IP + src) or src 0011 1100 ssss ssss 6
{L/S}JUMP NE, src If E=0, IP  (IP + src) or src 0111 1100 ssss ssss 6
{L/S}JUMP S, src If S=1, IP  (IP + src) or src f100 1100 ssss ssss 6
{L/S}DJNZ LC[n], src If --LC[n] <> 0, IP (IP + src) or src f10n 1101 ssss ssss 6
{L/S}CALL src @++SP  IP+1; IP  (IP+src) or src f011 1101 ssss ssss 6,7
RET IP  @SP-- 1000 1100 0000 1101
RET C If C=1, IP  @SP-- 1010 1100 0000 1101
RET NC If C=0, IP  @SP-- 1110 1100 0000 1101
RET Z If Z=1, IP  @SP-- 1001 1100 0000 1101
RET NZ If Z=0, IP  @SP-- 1101 1100 0000 1101
RET S If S=1, IP  @SP-- 1100 1100 0000 1101
RETI IP  @SP-- ; INS 0 1000 1100 1000 1101
RETI C If C=1, IP  @SP-- ; INS 0 1010 1100 1000 1101
RETI NC If C=0, IP  @SP-- ; INS 0 1110 1100 1000 1101
RETI Z If Z=1, IP  @SP-- ; INS 0 1001 1100 1000 1101
RETI NZ If Z=0, IP  @SP-- ; INS 0 1101 1100 1000 1101
RETI S If S=1, IP  @SP-- ; INS 0 1100 1100 1000 1101
D
A
TA
TR
A
N
S
F
E
R
XCH Swap Acc bytes 1000 1010 1000 1010 S Y
XCHN Swap nibbles in each Acc byte 1000 1010 0111 1010 S Y
MOVE dst, src dst  src fddd dddd ssss ssss C,S,Z,E (Note 8) 7,8
PUSH src @++SP  src f000 1101 ssss ssss 7
POP dst dst  @SP-- 1ddd dddd 0000 1101 C,S,Z,E 7
POPI dst dst  @SP-- ; INS  0 1ddd dddd 1000 1101 C,S,Z,E 7
CMP src E  (Acc = src) f111 1000 ssss ssss E
NOP No operation 1101 1010 0011 1010
Note 1: The active accumulator (Acc) is not allowed as the src in operations where it is the implicit destination.
