DS4830 User’s Guide
31
SECTION 4 – PERIPHERAL REGISTER DESCRIPTIONS
Reg M0 M1 M2 M3 M4 M5
0 PO2 I2CBUF-M I2CBUF-S MCNT DACD0 QTDATA
1 PO1 I2CST-M I2CST-S MA DACD1 QTCN
2 PO0 I2CIE-M I2CIE-S MB DACD2 LTIF
3 EIF2 PO6 ADCN MC2 DACD3 HTIF
4 EIF1 SPIB_S DADDR MC1 DACD4 SPIB_M
5 EIF0 MIIR1 SENR MC0 DACD5 PWMDATA
6 GTV1 EIF6 ADST GTV2 DACD6 PWMCN
7 GTCN1 EIE6 ADADDR GTCN2 DACD7 PWMSYNC
8 PI2 PI6 MIIR2 MC1R DACCFG LTIE
9 PI1 SVM ADDATA MC0R HTIE
10 PI0 TWR GTC2 QTLST
11 GTC1 TEMPCN
12 I2CCN-M I2CCN-S
13 EIE2 I2CCK-M I2CCK-S
14 EIE1 I2CTO-M I2CTO-S
15 EIE0 I2CSLA-M I2CSLA-S
16 PD2 EIES6 SHCN
17 PD1 PD6
18 PD0 SPICN_S PINSEL SPICN_M
19 EIES2 SPICF_S SPICF_M
20 EIES1 SPICK_S SPICK_M
21 EIES0 I2C_SPB
22 ETS
23 ADCG1
24 ADCG2 ICDT0
25 ADVOFF ICDT1
26 TOEX ICDC
27 ADCG3 ICDF
28 ADCG4 ICDB
29 CHIPREV ICDA
30 ICDD
31
