3.16 Frame Pointer Offset Register (OFFS, Eh[3h])
Initialization: This register is cleared to 00h on all forms of reset.
Access: Unrestricted direct read/write access.
BIT DESCRIPTION
7:0
This 8-bit register provides the Frame Pointer (FP) offset from the base pointer (BP). The Frame Pointer is formed by
unsigned addition of Frame Pointer Base Register (BP) and Frame Pointer Offset Register (Offs). The contents of this
register can be post-incremented or post-decremented when using the Frame Pointer for read operations and may be
pre-incremented or pre-decremented when using the Frame Pointer for write operations. A carry out or borrow resulting
from an increment/decrement operation has no effect on the Frame Pointer Base Register (BP).
3.17 Data Pointer Control Register (DPC, Eh[4h])
Initialization: This register is cleared to 001Ch on all forms of reset.
Access: Unrestricted direct read/write access.
BIT NAME DESCRIPTION
15:5 RESERVED Reserved. All reads return 0.
4 WBS2
Word/Byte Select 2. This bit selects access mode for BP[Offs]. When WBS2 is set to logic 1, the BP[Offs] is operated in word
mode for data memory access; when WBS2 is cleared to logic 0, BP[Offs] is operated in byte mode for data memory access.
3 WBS1
Word/Byte Select 1. This bit selects access mode for DP[1]. When WBS1 is set to logic 1, the DP[1] is operated in word mode
for data memory access; when WBS1 is cleared to logic 0, DP[1] is operated in byte mode for data memory access.
2 WBS0
Word/Byte Select 0. This bit selects access mode for DP[0]. When WBS0 is set to logic 1, the DP[0] is operated in word mode
for data memory access; when WBS0 is cleared to logic 0, DP[0] is operated in byte mode for data memory access.
1:0 SDPS[1:0]
Source Data Pointer Select Bits[1:0]. These bits select one of the three data pointers as the active source pointer for the load
operation. A new data pointer must be selected before being used to read data memory:
SDPS1 SDPS0 SOURCE POINTER SELECTION
0 0 DP[0]
0 1 DP[1]
1 0 FP (BP[Offs])
1 1 Reserved (select FP if set)
These bits default to 00b but do not activate DP[0] as an active source pointer until the SDPS bits are explicitly cleared to 00b or
the DP[0] register is written by an instruction. Also, modifying the register contents of a data/frame pointer register (DP[0],
DP[1], BP or Offs) will change the setting of the SDPS bits to reflect the active source pointer selection.
3.18 General Register (GR, Eh[5h])
Initialization: This register is cleared to 0000h on all forms of reset.
Access: Unrestricted direct read/write access.
BIT DESCRIPTION
15:0
This register is intended primarily for supporting byte operations on 16-bit data. The 16-bit register is byte-readable, byte-
writeable through the corresponding GRL and GRH 8-bit registers and byte-swappable through the GRS 16-bit register.
3.19 General Register Low Byte (GRL, Eh[6h])
Initialization: This register is cleared to 00h on all forms of reset.
Access: Unrestricted direct read/write access.
BIT DESCRIPTION
7:0
This register reflects the low byte of the GR register and is intended primarily for supporting byte operations on 16-bit data.
Any data written to the GRL register will also be stored in the low byte of the GR register.
3.20 Frame Pointer Base Register (BP, Eh[7h])
Initialization: This register is cleared to 0000h on all forms of reset.
Access: Unrestricted direct read/write access.
BIT DESCRIPTION
15:0
This register serves as the base pointer for the Frame Pointer (FP). The Frame Pointer is formed by unsigned addition of
Frame Pointer Base Register (BP) and Frame Pointer Offset Register (Offs). The content of this base pointer register is not
affected by increment/decrement operations performed on the offset (OFFS) register.
3.21 General Register Byte-Swapped (GRS, Eh[8h])
Initialization: This register is cleared to 0000h on all forms of reset
Access: Unrestricted read-only access.
BIT DESCRIPTION
15:0
This register is intended primarily for supporting byte operations on 16-bit data. This 16-bit read only register returns the
byte-swapped value for the data contained in the GR register.
