DS4830 User’s Guide
52
7.2
– ADC Register Descriptions
The ADC is controlled by ADC SFR registers. The PINSEL register is used to configure pins as analog pin for ADC use.
Four of the registers, ADST, ADADDR, ADCN, and ADDATA are used for setup, control, and reading from the ADC.
There are few other registers, ETS, ADCG1-4, ADVOFF, and TOEX, which are used to adjust the gains and offsets
applied to ADC results. To avoid undesired operations, the user should not write to bits labeled as “Reserved”.
7.2.1
– ADC Control Register (ADCN)
Register Address: M2[03h]
Bit
15
14
13
12
11
10
9
8
7
6
5
5
3
2
1
0
Name
ADCCLK[2:0]
NUM_SMP[4:0]
ADDAINV ADCONT
ADDAIE LOC_OVR
ADACQ[3:0]
Reset
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Access
rw*
rw*
rw*
rw*
rw*
rw*
rw*
rw*
rw*
rw*
rw*
rw*
rw*
rw*
rw*
rw*
* Unrestricted read, but can only be written to when ADCONV = 0.
BIT
NAME
DESCRIPTION
15:13
ADCCLK[2:0]
ADC Clock Divider. These bits select the ADC conversion clock in relationship to the
Core Clock.
ADCCLK[2:0]
ADC Clock
000
System Clock/8
001
System Clock/10
010
System Clock/12
011
System Clock/14
100
System Clock/16
101
System Clock/18
110
System Clock/20
111
System Clock/40
12:8
NUM_SMP[4:0] Interrupt After Number of Sample. These bits define interrupt after Number of ADC
Samples an
d are used with ADDAINV. If ADDINV is set to ‘1’, then ADC Interrupt will
occur after (NUM_SMP + 1) ADC samples and End of Sequence.
7
ADDAINV
ADC Data Available Interrupt Interval. This bit selects the condition for setting data
available interrupt flag (ADDAI).
When ADDAINV = 0, ADDAI is set after End of Sequence.
When ADDAINV = 1, ADDAI is set after End of Sequence and after ADC Samples =
(NUM_SMP + 1).
6
ADCONT
ADC Continuous Sequence Mode.
Setting this bit to ‘1’ will enable the continuous
sequenc
e mode. Clearing this bit to ‘0’ will disable the continuous sequence mode. In
single sequence mode, the ADC conversion will stop after the end of the sequence. The
user should set this bit to ‘1’, when temperature and sample and hold are also enabled.
5
ADDAIE
ADC Data Available Interrupt Enable. Setting the ADDAIE bit to
‘1’ will enable an
interrupt to be generated when the ADDAI=1. Clearing this bit to ‘0’ will disable an interrupt
from generating when ADDAI=1.
4
LOC_OVR
Location override bit. Setting
this bit to ‘1’ will enable the user to select an alternate
location for storing ADC conversion results. The alternate location is defined by
ADDATA[12:8] (ALT_LOC). By default, the ADC conversion results are stored in ADC
buffer location corresponding to channel number. Refer Table 7-1.
3:0
ADACQ[3:0]
ADC Acquisition Extension Bits [3:0]. These bits are used to extend sample acquisition
time if the corresponding ADC Acquisition Extension is enabled (ADDATA.ADACQEN =1
when ADST.ADCFG
is set to ‘1’). See ADC Conversion Time Section for details. The ADC
acquisition extension should not be used when the fast comparator is used for the same
channel.
