3-12 SmartSwitch 1800 4. 0 User G uide, Rev 01
E Configure IP/LLC2/BRIDGE/IPX Interfaces
A
Review IP Interfaces – (Chapter 14) displays information on any
IP interfaces (see below) configured in the SmartSwitch.
B Configure IP Interfaces – (Chapter 14) specifies addressing and
operating parameters for IP interfaces (X.25, frame relay, or LAN).
C Review Bridge Ports / LLC2 Interfaces – (Chapter 9, Chapter 16)
displays information on any bridge or LLC2 interfaces (see below)
configured in the SmartSwitch 1800.
D Configure Bridge Ports / LLC2 Interfaces – (Chapter 9,
Chapter 16) specifies location, type, and format of any bridge or
LLC2 interfaces.
E Review IPX Interfaces – (Chapter 15) displays information on
any IPX interfaces (see below) configured in the SmartSwitch.
F Configure IPX Interfaces – (Chapter 15) identifies any IPX
interfaces. Identifies type (X.25, Ethernet, etc.) and operating
parameters.
F Configure BSC Devices (Chapter 10)
A Review BSC Device Configuration – displays information on any
BSC Interactive devices (see below) configured in the SmartSwitch.
B Configure BSC Devices – identifies devices using SmartSwitch
ports configured as BSC Interactive.
D Configure Connections and Routing Paths
A
Review Subscriber IDs – (misc. chapters) displays information on
any subscriber IDs (see below) configured in the SmartSwitch.
B Configure Subscriber IDs – (Chapter 8 and misc. chapters)
identifies end users of the SmartSwitch, and specifies parameters for
redirecting traffic to other ports.
C Review Abbreviated Addresses – (Chapter 12) displays information
on any abbreviated addresses (see below) configured in the
SmartSwitch.
D Configure Abbreviated Addresses – (Chapter 12) specifies short
versions of subscriber IDs that can be used in place of the full
addresses for async PAD subscribers.
E PVC Configuration – (Chapter 7 [ frame relay ], Chapter 8 [ X.25 ],
Chapter 12 [ async ]) displays/specifies "permanent" connections
between SmartSwitch 1800 ports.
A Review PVC Configuration
B Configure PVCs
F Review IP Routing – (Chapter 14) displays information on any IP
routes (see below) configured in the SmartSwitch.
G Configure IP Routing – (Chapter 14) defines routes for IP traffic
through the SmartSwitch 1800.
H Review IPX Routing – (Chapter 15) displays information on any IPX
routes (see below) configured in the SmartSwitch.
I Configure IPX Routing – (Chapter 15) defines routes for IPX traffic
through the SmartSwitch.
E Configure Frame Relay Backup Groups – (Chapter 7) allows creation of
one or more frame relay ports/DLCIs that will act as backup(s) for a
port.
A Review Frame Relay Backup Groups
B Configure Frame Relay Backup Groups
