St atistics Displays 21-9
Calling.
Failed.
● Received Frames from Network – is the number of Voice frames received.
● Transmitted Frames to Network – is the number of Voice frames transmitted.
● Congestion Management Frames from Network – is self-explanatory.
● Congestion Management Frames to Network – is self-explanatory.
● Call Setup Time (msec) – is self-explanatory.
● Call Duration (secs) – is self-explanatory.
● Number Dialed – is self-explanatory.
● Baud Rate (Kbits/sec) – is self-explanatory.
● Interface Under-runs – is the number of frames that were not accepted due to
DMA (direct memory access) overrun errors.
● Interface Over-runs – is the number of frames that were not accepted due to
DMA (direct memory access) underrun errors.
Bridge Port Statistics
Press [A] at the Bridge Status Displays Menu to display the configurational and oper-
ational status of all Bridge ports in the node.
Figure 21-9 Bridge Port Status Display
[C],[F],[D],[A] from Main Menu
To display statistics for the Bridge ports on the above screen, press [F2] . Pressing
[PgUp] or [PgDn] will display other statistics screens (if there are more), and pressing
[F2] will return the display to Figure 21-9.
Node N ame= node_xyz
Brid ge Port Status Disp lay
Brid ge Id: 0010.00000364439B R oot Port: 255
Num Type/Format S tatus Bridge State Receive Xmit
0 Ethernet A ctive Disabled 4294967296 4294967296
1 Token Ring A ctive Lis ten in g 4675561234 4675561234
2 Frm/Nat LLC2 A ctive Learning 4561230000 4562222100
3 Frm/8023/TB A ctive Blocking 4561231100 4561231100
PgUp PgD n F2:More I nfo F3:Exit
