Configuring Voice 13-17
Figure 13-7 Voice Interface Configuration Menu
[A],[F],[F] from Main Menu
Voice Interface Parameters
The parameters that can be configured are listed in the following table. Explanations
follow the table.
1 Not used if the peer node is a SmartSwitch 1800.
Interface Peer Node Type
specifies whether the node at the remote end of the frame relay connection is a Smart-
Switch 1800 or another decice.
Peer Node Number (Default)
is the Switch number of the remote device.
Peer Node Port (Default)
is the Port number on the remote device.
Table 13-6 Voice Interface Configuration Parameters
Parameter Valid Values Default Value
Interface Peer Node Type Default, Smar tSwitch 1800 Default
Peer Node Number (Defaul t) 1–61 1 1
Peer Node Port (Default) 0–15 1 0
Local Node Num ber (Default) 1–61 1 2
Local Node Port (Default) 0–15 1 1
Fr ame Relay Port 0–3 0
Fr ame Relay DLCI 16–991 16
Nod e Name=n ode_xyz
V oice In terface Con figu ration Parameters
* Interface Numb er 1
A Interface Peer Node Typ e SmartSw itch 1800
B Peer Nod e Numb er (D efau lt) 1
C Peer Nod e Port (D efau lt) 0
D Local Node N umber (Default) 2
E Local Node Port (D efault) 1
F Frame R elay Port 0
G Frame R elay D LCI 16
H Enable Fragmen tation N
Option:
