Displaying sdlc pu status, Displaying sdlc pu status -20, 10 sdlc pu status display -20 – Cabletron Systems 1800 User Manual
Page 318: Sdlc pu status
20-20
SmartSwitch 1800 4. 0 User G uide, Rev 01
●
Backup Pend/Hold
– (Primary DLCI only) A backup DLCI is attempting to be
located. Received data will be queued on the primary DLCI's queue.
●
Backup Pend/Discard
– (Primary DLCI only) A backup DLCI is attempting to
be located. Received data will be discarded.
Displaying SDLC PU Status
To display the status of all PUs on an SNA port, press
[C]
at the Protocol Status Dis-
plays Menu. When prompted, enter:
●
RLP: Press
[Enter]
, accepting the dafault (and only valid value) of
0
.
●
Port:
0–7
for physical ports,
8–63
for logical ports. Valid numbers for physical
ports depend on the model of SmartSwitch 1800—see port locations on
.
Figure 20-10 SDLC PU Status Display
[C], [F],[C]
from Main Menu
Information in this Display:
●
– (specified when configuring the SNA port) identifies the PU,
and must match the
ADDR
parameter set in the macro PU in the VTAM config-
uration. (The station address is usually set to
C1
for point-to-point SDLC lines,
and in series
C1, C2, C3
, etc. for multidrop lines.)
●
Name
– PU name configured in the PU parameters in the SNA Port record.
●
State
– will be one of these:
◆
Active
◆
Inactive
◆
Never_Activated
◆
Pending_Contact
– waiting for Normal Response Mode
Node Name=nod e_xyz
SD LC PU Statu s D is play for R LP: 0
Port: 2
Station Add ress
Name
S tate
D1
Pu d1
N ever_A ctivated
D2
Pu d2
A ctive
