20-4
SmartSwitch 1800 4. 0 User G uide, Rev 01
Figure 20-3 Virtual Connections Display on Frame Relay Port
[C],[C]
from Main Menu
Information in this Display:
●
Seq
– is a sequence number used to identify the connection.
●
DLCI
– is the DLCI on which the connection exists.
●
State
:
Data_trans
– means that call processing was successful and the con-
nection is in the data transmission state.
Call_setup
– means that the attached device is waiting for Call Accept.
Clearing
– means that the attached device is in Call Clear state, waiting
for Clear Confirmation.
Resetting
– means that a Reset has been sent to the remote device, and the
attached device is waiting for a Reset Confirmation.
Port_down
– is self-explanatory.
Connected
– means that a connection has been established.
Not_conect
– means that a connection has not been established or has
been broken.
A frame relay DLCI displaying this state might have a backup that
is now in operation. To determine this, press
[F3]
to return to the
Status Displays
menu, then press
[F]
,
[E]
,
[B]
(
Display States for all
Primary DLCIs on a Port
), and enter the port number. If the DLCI is
displayed as
Backed Up
, note the backup DLCI, then press
[F3]
three times, then
[C]
at the Status Displays menu, and verify that
the backup DLCI is in
Data_trans
state.
●
Undefined
– means that the port is in some unknown state.
●
Trans
– is the number of transmitted frames.
●
Recd
– is the number of received frames.
●
Disc
– is the number of discarded frames.
N ode N ame= node_xyz
C onnection S tatus Display Menu (Page 1)
RLP: 0
Port: 0
From:
C u m u l a t i v e
To:
S eqDLCI
S tate
Tran s
R ecd
Disc
P
DLC I S tate
1
16
D ata_tran s
587
497
0
9
16
D ata_tran s
2
17
D ata_tran s
588
574 0
10
17
D ata_tran s
3
18
D ata_tran s
592
586 1
11
18
D ata_tran s
4
20
D ata_tran s
580
486 0
14
20
D ata_tran s
5
32
D ata_tran s
585
602 6
18
28
D ata_tran s
6
33
D ata_tran s
600
594 0
19
29
D ata_tran s
7
34
D ata_tran s
621
600 0
22
30
D ata_tran s
8
35
D ata_tran s
579
543 0
23
31
D ata_tran s
9
36
D ata_tran s
586
584 0
24
32
D ata_tran s
10 25
D ata_tran s
588
586 4
30
25
D ata_tran s
11 24
D ata_tran s
593
610
0
29
24
D ata_tran s
12 42
D ata_tran s
602
498
5
33
42
D ata_tran s
13 43
D ata_tran s
610
506
0
34
43
D ata_tran s
14 44
D ata_tran s
585
560
0
35
44
D ata_tran s
