Configuring SNA 9-19
Figure 9-6 LLC2 Originated Host Configuration Screen
[A],[A], [E],[D] from Main Menu
Pressing [M] will display a screen similar to Figure 9-8.
Figure 9-7 LLC2 Terminated Host Configuration Screen
[A],[A], [E],[D] from Main Menu
Pressing [M] will display a screen similar to Figure 9-8.
Nod e Name=n odexyz
S NA LLC2 Origin ated S es sion C onfiguration (Screen 1 of 2)
* Hos t N umber: 1
A Hos t MAC Ad dres s 0C005A 123402
B Session Type Originated
C T1 (100 msec) 10
D T2 (ms ec) 100
E Ti 30
F N3 1
G Tw 1
H N2 8
I Priority 0
J Bandw id th Allocation Group 1
K Routing Su bscrib er I D 1121000000*
L Source MAC Add ress Mask 40000470
M Conn ections - S creen 2
Option:
N ode N ame= nodexyz
SNA LLC2 Terminated Session Con figu ration (Screen 1 of 2)
* Host Numb er: 1
A Host MA C A ddress 0C 005A123402
B Sess ion Typ e Termin ated
C T1 (100 msec) 10
D T2 (msec) 100
E Ti 30
F N3 1
G Tw 1
H N2 8
I Priority 0
J Band width Allocation Group 1
K Rou tin g S ubs criber ID 1121000000*
L Con nections - Screen 2
Op tion :
