14-6 SmartSwitch 1800 4. 0 User G uide, Rev 01
Figure 14-3 LAN IP Interface – Secondary Address Configuration
Up to 15 secondary IP addresses can be configured on a LAN interface, providing
support for multiple IP subnets on the same physical LAN segment.
To configure a secondary address, press [A] . The selected address will be highlighted
in reverse video. To select a different address, press a number from 1–15 , corre-
sponding to the sequence ( Seq ) number of the entry. (Pressing any valid number
higher than the highest configured number will display a new entry for the next
sequential number after the highest configured number.
When a secondary IP address (item B) is entered, default values will be displayed for
items C and D.
To delete an existing entry, press [G] , then [Y] when asked to confirm. Any entries with
higher sequence numbers will move up one to fill in the gap.
To delete a primary address ( Source IP Address on the first screen) without
deleting the group of associated secondary addresses, do this:
1.Select one of the secondary addresses to be the new primary.
2.Delete that secondary address.
3.Reconfigure the Source IP Address to specify the secondary address that
was deleted.
Node Name=nod exyz
I P In terface Configuration - Screen 2
I nterface N umber: 0
S econd ary IP A ddress Con figu ration
A B C D E F G
Seq Sec. I P Ad dr N et Mas k Bcast Ad dr RMetric R IP S upp ort Del
1 10.10.10.10 55.55.55.0 10.10.10.255 0 0
Option:
