Net View Management D-5
Keywords when the PU is being modified are listed below. The
parameters are listed in, and described following,
Table 9-2 .
Corresponding Parameter
Keyword in SmartSwitch 1800 Valid Values
LOCALSUB Local Subscriber ID 0–15 characters
REMOTESUB Remote Subscriber ID 0–15 characters
ATCL Autocall Y/N
RTYTM Autocall Retry Time 15–255 (sec)
RTYCT Autocall Retry Count 0–255
ADDR Station Address 0–FF
ISTATUS Istatus Active, Inactive
LOCALSAP Local SAP Address 0–FC
LOCALMAC Local MAC Address 0–FFFFFFFFFFFF
IDBLK IDBLK 0–FFF
IDNUM IDNUM 0–FFFFF
LANTI Ti 1–50 (sec)
LANT1 T1 0–250 (ms)
LANT2 T2 100–5000 (ms)
LANN2 N2 0–255
LANN3 N3 1–127
LANTW Tw 1–127
BAG Bandwidth Allocation Group 0–16
MAXDATA Maxdata 25–4105
Command: F NET, CONFIG,COMMIT
Option: COMMIT will update the SmartSwitch 1800 database value(s)
with all changes made since the last COMMIT , on-line update of the
record, or node IPL.
Unlike the [F7] on-line update of a database record as per-
formed locally on a SmartSwitch 1800, sending a CONFIG
and a COMMIT do not disable the port, since they update the
node’s system memory and database values separately,
instead of writing one set of values to the other.
