9-20 SmartSwitch 1800 4. 0 User G uide, Rev 01
Figure 9-8 LLC2 Host Connections Screen
This example shows a configuration for an Originated session. A display
for a Terminated session will not have columns E–J as shown, but instead
will simply have column E,
Del . In either case, selecting Del after selecting
a sequence ( Sq ) number will delete that line.
Node Name=nod exyz
SN A LLC 2 Originated Session Con figu ration (Screen 2 of 2)
*
Host Numb er: 1
A B C D EF G H I J
Sq HSA P Local Su b Remote S ub TypeIDBLKID NUMMaxDataMaxIn D el
1 04 112100000011* 6554433222* SDLC 01700001 4105 128
2 04 112100000012* 6554433223* SDLC 01700002 4105 128
3 04 112100000015* 6554433225* LLC2
4 04 112100000016* 6554433226* SDLC 01700003 265 7
5 04 112100000020* 6554433228* LLC2
Option:
