2-8 SmartSwitch 1800 4. 0 User G uide, Rev 01
ESC: Quit —abandons the changes you have made since the last save (via [F3] or [F7] )
and returns you to the previous menu.
Character: Select Option or Change Field :
Select Option —appears if an option has not yet been selected.
Change Field —Press the letter corresponding to the field you want to change, then
type in the new information and press [Enter] .
PgUp , PgDn —allows you to display multiple screens (one at a time) for a record, if the
record has more than one.
Function Keys on an ASCII Terminal
Standard PC keyboard function keys are represented as follows on an ASCII terminal
keyboard. Note that
^[O (under "Maps to:") is an escape character followed by an
uppercase letter O.
PC ASCII
Keyboard Keyboard Maps to:
[F1] [PF1] ^[OP
[F2] [PF2] ^[OQ
[F3] [PF3] ^[OR
[F4] [PF4] ^[OS
[F5] [5] ^[Ou
[F6] [6] ^[Ov
[F7] [7] ^[Ow
[F9] [,] (comma) ^[Ol
[F10] [.] (period) ^[On
[PgUp] [ ] ^[OA
[PgDn] [ ] ^[OB
