21-8 SmartSwitch 1800 4. 0 User G uide, Rev 01
The statistic names in this display are self-explanatory (except the Version of DSP
Image , which is not currently displayed.
Voice Connection Statistics
To display Voice Connection statistics for both Voice ports, press [B] at the Voice Sta-
tistics Displays Menu. When prompted, enter:
● Port : 4 or 5 .
● Report Interval : 5–65535 (seconds). (Default is 5 .)
Figure 21-8 Voice Connection Statistics Display
[E],[I],[B] from Main Menu
As this manual was going to press, there was a possibility that the
above display would change to clarify the information shown for
Source and Destination at the top of the screen. The correct descrip-
tions of those items are in the list below.
Information in this Display:
● Source: RLP, Port – Identifies the local Voice port. ( RLP is irrelevant, and will
always be 0 .)
● Destination: Node – identifies the device at the remote end of the frame relay
connection.
● Destination: RLP, Port, DLCI – identify the local frame relay interface that will be
used to transport Voice frames.
● Call State – will be one of these:
On Hook .
Off Hook .
Call Active – a call has been placed and answered
Pending – the call has timed out during a busy condition, but the receiver is
still off hook.
Loading.
Nod e Name=nod e_xyz
V oice C onnection Statistics D is play
Sou rce R LP: 0 Port: 5
Destination: N ode: 110 R LP: 0
Port: 0 D LCI: 16
Report Interval (sec): 5
Cu rrent Time: 01/07/1998
14:23:45
STA TISTI CS
Call S tate
Id le
Frames Received from Network 100
Frames Transmitted to Network 110
Con ges tion Management from Network 0
Con ges tion Management to Network 0
Call S etu p Time (ms ec) 100
Call D uration (secs) 1:14
Nu mber Dialed 100100
Baud R ate 9600
In terface Un derrun s 0
In terface Overruns 0
