15-6 SmartSwitch 1800 4. 0 User G uide, Rev 01
Service Type Value
is a SAP Service Type code. Some common types are:
0003 = print queue 0004 = file server 0005 = job server
0007 = print server 0009 = archive server 0024 = remote bridge server
Server Name
identifies a specific server whose incoming/outgoing packets will be affected by the
SAP filter.
Network Address Value
is an IPX network number assigned to the network containing the server identified by
Server Name .
Node Address Value
identifies the node to which the filter will be applied.
Socket Address Value
is an IPX socket number that identifies a process or protocol. Some Novell socket
numbers are:
0451 = NCP Process 0452 = SAP Process 0453 = RIP Process
0455 = NetBIOS Process 0456 = Diagnostics Process
Filter Name
helps the user identify the filter. The name is not used by the software.
Table 15-4 IPX Packet Filter Parameters
Parameter Valid Values Default Value
Filter Name 1–31 characters none
Packet Type Value 0–ff (1 byte) ff
Packet Type Mask 0–ff (1 byte) ff
Desti nation Network Val ue 0–ffffffff (4 bytes) ffffffff
Desti nation Network Mask 0–ffffffff (4 bytes) ffffffff
Desti nation Node Value 0–ffffffffffff (6 bytes) ffffffffffff
Desti nation Node Mask 0–ffffffffffff (6 bytes) ffffffffffff
Desti nation Socket Value 0–ffff (2 bytes) ffff
Desti nation Socket Mask 0–ffff (2 bytes) ffff
Source Netw or k Value 0–ffffffff (4 bytes) ffffffff
Source Network Mask 0–ffffffff (4 bytes) ffffffff
Source Node Val ue 0–ffffffffffff (6 bytes) ffffffffffff
Source Node Mask 0–ffffffffffff (6 bytes) ffffffffffff
Source Socket Value 0–ffff (2 bytes) 0451
Source Socket Mask 0–ffff (2 bytes) 0451
