9-26 SmartSwitch 1800 4. 0 User G uide, Rev 01
Configuring LLC2 Interfaces
LLC2 Interfaces records define the types and locations of the interfaces that will carry
LLC2 traffic to or from a SmartSwitch 1800.
To display configured interfaces, press [C] at the IP/LLC2/BRIDGE.IPX Interfaces
Configuration Menu.
Figure 9-9 LLC2 Interfaces Display
[A],[C],[E],[C] from Main Menu
These interfaces can be used for either LLC2 or Bridging. Also note that
the
RLP column is irrelevant on the SmartSwitch 1800.
To configure an interface, press [D] at the LAN Interfaces Configuration Menu. When
prompted for an interface number (which is merely a sequential number to identify the
interface):
●
If modifying an existing record, enter the interface number: 0–95 .
●
If creating a new record, press [Enter] , which will automatically specify the next
available sequential interface number.
The display depends on the interface type. Examples are shown in the following two
figures.
Nod e Name=n odexyz
R eview Bridge Ports/LLC -2 I nterfaces
----------------------------------------------------------------------------------------------------------------------
I nterface Nu mberTyp e RLP
Port DLC I Format
-----------------------------------------------------------------------------------------------------------------------
1
Ethern et
2 Frame Relay 0 1 30 Native LLC -2
3 Frame Relay 0 1 31 8025_SR B
4 Frame Relay 0 1 32 8025_SR B
5 Frame Relay 0 1 33 8023_TB
PgUp , PgD n, F3:Exit, F9:Stop Remote, F10:Abort
