St atistics Displays 21-7
Information in this Display:
● CIR In/Out – Committed Information Rate s configured in the Port record.
● Bc In/Out – Committed Burst Size s configured in the Port record.
● Be In/Out – Excess Burst Size s configured in the Port record.
● Committed Data In/Out – incoming/outgoing data that is within CIR.
● Excess Data In/Out – incoming/outgoing data that is above CIR but within B
E
.
● Frames Rcvd – total number of frames received on the port since the last IPL of
the node or enabling of the port.
● Disc – total number of frames discarded on the port since the last IPL of the node
or enabling of the port.
● Frames Xmit – total number of frames transmitted on the port since the last IPL
of the node or enabling of the port.
● BAG – Bandwidth Allocation Group.
● Conf/Act Percentage – configured and actual percentages of bandwidth used by
traffic assigned to each group.
● Actual (bits/sec) – current bandwidth usage by traffic assigned to each group.
Voice Statistics
Voice Application Statistics
To display Voice Application statistics for both Voice ports, press [A] at the Voice Sta-
tistics Displays Menu and, when prompted, enter a Report Interval : 5–65535 (seconds).
(The default is 5 .) The display will show current and cumulative (from the last IPL of
the node or clearing of the values) values for the statistics listed below. The cumu-
lative statistics values can be cleared (reset to zero) by pressing
[F4] .
Figure 21-7 Voice Connection Statistics Display
[E],[I ],[A] from Main Menu
Nod e Name=nod e_xyz
Voice App lication Statistics Display
Report I nterval (s ec): 5
Curren t Time: 01/07/1998
14:23:45
POR T 4 PORT 5
STATI STIC S CU RR C UMULATI VE C URR CU MU LATIV E
Incoming Calls Received 2 100 2 100
Ou tgoin g C alls Placed 2 100 2 100
Calls Termin ated (Received) 2 100 2 100
Calls Termin ated (Sent) 2 100 2 100
Ou tgoin g C alls Accepted 2 100 2 100
Incoming Calls Accep ted 2 100 2 100
Ou tgoin g C alls Rejected 2 100 2 100
Ou tgoin g C alls Timed Out 2 100 2 100
Vers ion of DSP Image
F4:C lear C umulative Statistics , Oth ers: Exit
