18-4 SmartSwitch 1800 4. 0 User G uide, Rev 01
F Protocol Status
A
IPX RIP Table Display – displays the contents of the RIP table.
B IPX SAP Table Display – displays the contents of the SAP table.
C SDLC PU Status – displays a list of configured station addresses for a
specified SNA port, including current active/inactive states.
D Bridge Status Displays
A Bridge Port Status Display – displays a list of Bridge ports, including
type, active status, bridge state (forwarding, listening, etc.), and number
of bytes received and transmitted.
B Bridge Forwarding Table Display – displays a list of MAC addresses and
their associated bridge ports, plus any flags that have been set.
E Frame Relay Backup Status – displays the current state of frame relay
primary and backup DLCIs.
A Display States for all Backup DLCIs on a Port
B Display States for all Primary DLCIs on a Port
C Display States for all Backup DLCIs in a Group
F LLC/2 Session Status – displays addresses and operational states of all
current LLC2 sessions.
G IP Status Displays
A IP Routing Table Display – displays interfaces, destinations, network
masks, and flags.
B IP ARP Table Display – displays ARP IP addresses, MAC addresses, and
aging timers.
C IP Interfaces Display – displays interface names, MTU values, network
names, masks, IP and remote addresses, and flags.
H Voice IInterfaces Display – displays configured Voice interfaces.
D Events – (Chapter 22) Displays event (alarm) messages as they occur.
E Statistics (Chapter 21)
A Configure RLP / Port Thresholds – allows creation of a threshold for a statistic
that, when crossed, will cause an alarm to be generated.
B Display RLP / Port / Frame Statistics – displays the supported statistics for the
specified component, showing current values, as well as the highest values
reached by each statistic since the node was last booted or since maximum
values were last cleared.
C Display IP Statistics – displays the supported statistics, including current values
and cumulative values since maximum values were last cleared.
D Display ICMP Statistics – displays the supported statistics, including current
values and cumulative values since maximum values were last cleared.
E Display IP Interface Statistics – displays the supported statistics, including
current values and cumulative values since maximum values were last
cleared.
F Display IPX Interface Statistics – displays the supported statistics, including
current values and cumulative values since maximum values were last
cleared.
G Display LAN Card Interface Statistics – displays the supported statistics,
including current values and cumulative values since maximum values
were last cleared.
H Display Frame Relay Utilization Statistics – displays CIR, B
E
, and B
C
values for
a specified DLCI, as well as the configured and actual percentages of
bandwidth use by each bandwidth allocation group.
I Display Voice Statistics
A
Display Voice Application Statistics – displays data on calls received,
transmitted, cleared, and accepted, as well as busy and time-out statistics.
