Displays and Graphics
Chapter 8
8-25
2. Select a program. Press {SELECT PRGRAM}.
(softkey level 2)
SELECT
PRGRAM
QUICK
CHECK
STOP
CHECK
T PATH
GRAPH
T PATH
DISABL
3. Use the up and down cursors to select a program.
4. Press {ACTIVE PRGRAM} to return to level 2 and activate the
program.
Follow these steps to run graphics:
1. Press the {PRGRAM CHECK} softkey.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
2. Select a program. Press {SELECT PRGRAM}.
(softkey level 2)
SELECT
PRGRAM
QUICK
CHECK
STOP
CHECK
T PATH
GRAPH
T PATH
DISABL
3. Use the up and down cursors to select a program.
4. Select graphics. Follow the appropriate steps:
(softkey level 2)
SELECT
PRGRAM
QUICK
CHECK
STOP
CHECK
T PATH
GRAPH
T PATH
DISABL
SELECT
PRGRAM
QUICK
CHECK
STOP
CHECK
T PATH
GRAPH
T PATH
DISABL
(softkey level 2)
Active Graphics QuickCheck Graphics
GRAPH SYNTAX
ONLY
(softkey level 3)
The graphics you select remains active until you disable graphics.
5. Press the button to plot the part program.
8.4.2
Running Graphics
