Boom
3.2 Model 6042 Legacy Origin 7/02
3.1 BOOM SYSTEM COMPONENT
TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the boom system.
The following illustration identifies the components that
are referred to throughout this section.
FRONT
MA9160
Quick Attach
Attachment
Tilt Cylinder
Inner Boom Section
with Gooseneck
Outer
Boom
Section
Boom Extend/
Retract Cylinder
Intermediate
Boom Section
Extend Chains
Retract Chain
