Electrical System
9.24 Model 6042 Legacy Origin 7/02
9.7.9 Electrical Schematic Legend (Roadlight Harness)
Wire No. Gauge Color From - Function - To
1 12 RED Splice 1 to Console/Stabilizer Harness Fuse Block Connector (Wire 12A)
1A 14 RED Splice 1 to Worklight Switch (Pin 5)
1B 14
14 RED
RED Splice 1 to Hazard Switch (Pin 8)
Jumper from Hazard Switch (Pin 8) to Hazard Switch (Pin 1)
1C 14 RED Splice 1 to Lighting Control 3-Way Connector (Pin C)
1D 14 RED Splice 1 to Brake Pedal Switch (Pin 4)
1E 14 RED Splice 1 to Worklight Switch (Pin 2)
1F 14 RED Splice 1 to Worklight Switch (Pin 8)
2A 12 BLK Splice 2 to Cab Ground
2B 12 BLK Splice 2 to Hazard Switch (Pin 10)
2C 12 BLK Splice 2 to Roadlight Harness Connector (Pin B)
2D 12 BLK Splice 2 to Left Rear Worklight (GND)
2E 12 BLK Splice 2 to Left Taillight (GND)
2F 12 BLK Splice 2 to Right Taillight (GND)
2G 12 BLK Splice 2 to Right Rear Worklight (GND)
2H 12 BLK Splice 2 to Right Front Roadlight (GND)
2J 12 BLK Splice 2 to Left Front Roadlight (GND)
2K 12 BLK Splice 2 to Worklight Switch (Pin 7)
3A 14 LT BLU Worklight Switch (Pin 3) to Roadlight Harness Connector (Pin A)
4A 14 YEL Splice 4 to Worklight Switch (Pin 6)
4B 14 YEL Splice 4 to Left Rear Worklight (WORK LT)
4C 14 YEL Splice 4 to Right Rear Worklight (WORK LT)
20 16 WHT Splice 20 to Lighting Control 3-Way Connector (Pin A)
20A 16 WHT Splice 20 to Left Front Roadlight (SIDE LT)
20B 16 WHT Splice 20 to Right Front Roadlight (SIDE LT)
20C 16 WHT Splice 20 to Left Taillight (TAIL)
20D 16 WHT Splice 20 to Right Taillight (TAIL)
20F 16 WHT Splice 20A to Instrument Panel Connector (Wire 156) (Console/Stabilizer Harness)
21 16 RED Splice 21 to Lighting Control 3-Way Connector (Pin B)
21A 16 RED Splice 21 to Left Front Roadlight (DIP BEAM)
21B 16 RED Splice 21 to Right Front Roadlight (DIP BEAM)
21C 16 RED Splice 21 to Console/Stabilizer Harness Fuse Block Connector (Wire 21C)
22 16 ORG Splice 22 to Lighting Control 6-Way Connector (Pin E)
22A 16 ORG Splice 22 to Left Front Roadlight (IND)
22B 16 ORG Splice 22 to Left Taillight (IND)
22C 16 ORG Splice 22 to Hazard Switch (Pin 18)
23 16 GRN Splice 23 to Lighting Control 6-Way Connector (Pin D)
23A 16 GRN Splice 23 to Right Front Roadlight (IND)
23B 16 GRN Splice 23 to Right Taillight (IND)
23C 16 GRN Splice 23 to Hazard Switch (Pin 17)
24 16 DK BLU Splice 24 to Lighting Control 6-Way Connector (Pin A)
24A 16 DK BLU Splice 24 to Left Front Roadlight (MAIN BEAM)
24B 16 DK BLU Splice 24 to Right Front Roadlight (MAIN BEAM)
24C 16 DK BLU Splice 24 to Instrument Panel Connector (Wire 154) (Console/Stabilizer Harness)
25 16 PNK Splice 24 to Lighting Control 6-Way Connector (Pin B)
26 16 GRY Splice 26 to Brake Pedal Switch (Pin 5)
26A 16 GRY Splice 26 to Left Taillight (BRK)
26B 16 GRY Splice 26 to Right Taillight (BRK)
27 16 VIO/WHT Flasher (Pin P) to Instrument Panel Connector (Wire 155) (Console/Stabilizer Harness)
28 16 VIO Splice 28 to Flasher (Pin L)
28A 16 VIO Splice 28 to Lighting Control 6-Way Connector (Pin F)
28B 16 VIO Splice 28 to Hazard Switch (Pin 5)
31 16 YEL Console/Stabilizer Harness Fuse Block Connector (Wire 23) to Lighting Control 6-Way Connector (Pin C)
32 14 GRN Console/Stabilizer Harness Fuse Block Connector (Wire 12C) to Hazard Switch (Pin 3)
33 16 VIO Flasher (Pin X) to Hazard Switch (Pin 2)
BOOMLIGHT HARNESS WIRES
2B 14 BLK Boom Worklight Harness Connector (Pin B) to Boom Light (GND)
3D 14 LT BLU Boom Worklight Harness Connector (Pin A) to Boom Light (WORK LT)
