9.55 Model 6042 Legacy Origin 7/02
Electrical System
Replace roadlight
harness.
Not OK If OK
Replace brake
switch.
Before troubleshooting any
electrical circuit, ALWAYS
begin by checking the
following:
1. Fuses.
2. All connections relating
to circuit are clean and
tight.
3. Before troubleshooting
the brake lights circuit,
verify that the worklight
circuit is operating. If
not, follow the steps
listed at, Section 9.7.27,
“Roadlights Worklights
Circuit and
Troubleshooting
(Option),” before
troubleshooting the
brake lights circuit.
Not
OK
Replace roadlight
harness.
Not OK If OK
Replace bulb.
If OK
If one brake light is not
ON with the brake pedal
depressed, verify
voltage at that brake
light connector, pins
2E & 26A (Left Rear) or
2F & 26B (Right Rear).
Check for voltage at brake
pedal switch pin 4,
wire 1D (RED).
Check for voltage at
brake pedal switch
pin 5, wire 26 (GRY).
With the ignition ON and
the brake pedal depressed,
brake lights remain OFF.
