Model 6042 Legacy
Origin 7/02
Electrical System
If OK
Not
OK
Check for battery voltage at
wire 8 (LT GRN/WHT)
at steer select valve. Check
wire 2C (BLK) ground
connection.
With steer select switch
in crab steer mode,
only 2-wheel steering
is active.
Check wire 8 (LT GRN/WHT)
from steer select solenoid to
steer select switch. Check for
open orshort to ground.
Check resistance on steer
select valve solenoid for
5 to 7 ohms.
If OK
Check 10-amp
steer mode fuse.
Replace steer select
valve solenoid.
Refer to Section 8, “Hydraulic
additional information.
If OK
Not
OK
Before troubleshooting any
electrical circuit, ALWAYS
begin by checking the
following:
1. Fuses.
2. All connections relating
to circuit are clean and
tight.
