Electrical System
9.22
Model 6042 Legacy
Origin 7/02
9.7.7
Electrical Schematic Legend (Wiper/Washer and Heater Harnesses)
Wire No.
Gauge
Color
From
-
Function
-
To
WIPER/WASHER HARNESS WIRES (OPTION)
1
14
BLK
Splice 2 to Front Wiper Motor (Ground)
1A
14
BLK
Splice 2 to Front Wiper Switch (Pin 7)
1B
14
BLK
Splice 2 to Roof Wiper Switch (Pin 7)
1C
14
BLK
Splice 2 to Front & Roof Washer Switch (Pin 7)
1D
14
BLK
Splice 2 to Cab Ground
1E
14
BLK
Splice 2 to Roof Wiper Motor (Ground)
1F
14
BLK
Splice 2 to Front & Roof Washer Motor (Ground)
2
14
BLU
Front Wiper Switch (Pin 1) to Front Wiper Motor (HIGH)
3
14
WHT
Front Wiper Switch (Pin 3) to Front Wiper Motor (LOW)
4
14
GRN
Front Wiper Switch (Pin 6) to Front Wiper Motor (PARK)
5
14
YEL
Roof Wiper Switch (Pin 6) to Roof Wiper Motor (PARK)
6
14
RED/WHT
Splice 30 to Front Wiper Switch (Pin 9)
6A
14
RED/WHT
Front Wiper Switch (Pin 9) to Front Wiper Switch (Pin 5)
6B
14
RED/WHT
Splice 30 to Roof Wiper Switch (Pin 9)
6C
14
RED/WHT
Roof Wiper Switch (Pin 9) to Roof Wiper Switch (Pin 5)
6D
14
RED/WHT
Splice 30 to Front & Roof Washer Switch (Pin 8)
6E
14
RED/WHT
Front & Roof Washer Switch (Pin 8) to Front & Roof Washer Switch (Pin 3)
6F
14
RED/WHT
Splice 30 to Console/Stabilizer Harness Connector (Wire 32)
9
14
GRN
Roof Wiper Switch (Pin 1) to Roof Wiper Motor (ON)
10
14
GRN
Front & Roof Washer Switch (Pin 2) to Front & Roof Washer Motor (ON)
PUR
14
PUR
Front Wiper Switch Connector Jumper from Pin 2 to Pin 4
PUR
14
PUR
Roof Wiper Switch Connector Jumper from Pin 2 to Pin 4
HEATER HARNESS WIRES (OPTION)
1
14
YEL
Heater Switch (LOW) to Heater Blower Motor (LOW)
2
14
RED/WHT
Heater Switch (Power) to Console/Stabilizer Harness Connector (Wire 52)
3
14
ORG
Heater Switch (HIGH) to Heater Blower Motor (HIGH)
4
14
RED
Heater Switch (MED) to Heater Blower Motor (MED)
5
14
BLK
Heater Blower Motor (Ground) to Cab Ground
