Electrical System
9.18 Model 6042 Legacy Origin 7/02
42 18 TAN Instrument Panel Fuse to Park Brake Switch Connector (Pin 2)
Park Brake Switch Connector Jumper (Pin 2) to (Pin 8)
45 16 DK BLU/ORG Splice 45 to Splice 114
45A 16 DK BLU/ORG Splice 45 to Diode to Splice 152
45B 16 DK BLU/ORG Splice 45 to Brake Pedal Switch (Pin 1)
46 16 WHT/ORG Steer Select Switch Relay Fuse to Brake Pedal Switch (Pin 2)
47 16
16 ORG/WHT
ORG/WHT Stabilizer Lock Relay (Pin 87A) to Cab/Chassis Connector (Console/Stabilizer Harness)
Cab/Chassis Connector to Splice 47 (Engine Harness)
47A 16 PUR/WHT Splice 47 to Stabil-TRAK™ Cylinder (SOL 4A)
47B 16 PUR/WHT Splice 47 to Stabil-TRAK™ Cylinder (SOL 4B)
48 16 PUR/BLK Stabilizer Lock Relay (Pin 30) to Boom Switch Relay (Pin 87A)
49 16 RED/BLU Not Used (Engine Harness)
50 16 WHT/YEL Open Fuse to Option Connector
51 16 WHT/RED Open Fuse to Option Connector
52 12 ORG Horn/Heater Fuse to Heater Connector (Option)
101 16
16 BRN
BRN Shifter Connector (Pin 5) to Cab/Chassis Connector (Console/Stabilizer Harness)
Cab/Chassis Connector to Splice 101 (Engine Harness)
101A 16 BRN Splice 101 to Diode Pack (Pin B)
101B 18 BRN Splice 101 to Lower Transmission Connector (Pin 5, Solenoid Y5)
102 16
16 PNK
PNK Shifter Connector (Pin 3) to Splice 102 (Console/Stabilizer Harness)
Cab/Chassis Connector to Splice 102 (Engine Harness)
102A 16
16 PNK
PNK Splice 102 to Back-Up Alarm Relay (Pin 86) (Console/Stabilizer Harness)
Splice 102 to Diode Pack (Pin E) (Engine Harness)
102B 16
18 PNK
PNK Splice 102 to Cab/Chassis Connector (Console/Stabilizer Harness)
Splice 102 to Upper Transmission Connector (Pin 2, Solenoid Y2) (Engine Harness)
103 16
16 BLU
BLU Shifter Connector (Pin 7) to Cab/Chassis Connector (Console/Stabilizer Harness)
Cab/Chassis Connector to Splice 103 (Engine Harness)
103A 16 BLU Splice 103 to Diode Pack (Pin A)
103B 18 BLU Splice 103 to Upper Transmission Connector (Pin 3, Solenoid Y3)
104 16
16 YEL
YEL Shifter Connector (Pin 2) to Cab/Chassis Connector (Console/Stabilizer Harness)
Cab/Chassis Connector to Splice 104 (Engine Harness)
104A 16 YEL Splice 104 to Diode Pack (Pin E)
104B 18 YEL Splice 104 to Upper Transmission Connector (Pin 1, Solenoid Y1)
105 16
16 GRN
GRN Shifter Connector (Pin 6) to Cab/Chassis Connector (Console/Stabilizer Harness)
Cab/Chassis Connector to Splice 105 (Engine Harness)
105A 16 GRN Splice 105 to Diode Pack (Pin B)
105B 18 GRN Splice 105 to Lower Transmission Connector (Pin 4, Solenoid Y4)
106 12
12 BLU/ORG
BLU/ORG Neutral Start Relay (Pin 87) to Cab/Chassis Connector (Console/Stabilizer Harness)
Cab/Chassis Connector to Starter (Pin 50) (Engine Harness)
107 18 BLU Splice 41 to Park Brake Disconnect Relay (Pin 86)
111 12 RED Park Brake Switch (Pin 6) to Splice 111
111A 12 RED Splice 111 to Neutral Start Relay (Pin 30)
112 16 GRY Shifter Connector (Pin 4) to Splice 112
112A 16 GRY Splice 112 to Neutral Start Relay (Pin 86)
113 16 GRY Shifter Connector (Pin 1) to Splice 113
113A 16 RED Splice 113 to Diode to Splice 111
113B 16 RED Splice 113 to Park Brake Disconnect Relay (Pin 87)
114A 16 BLU/ORG Splice 112 to Diode to Splice 114
114B 16 BLU/ORG Splice 114 to Stabilizer Lock Relay (Pin 86)
150 16
16 VIO
VIO Shifter Connector (Pin 8) to Cab/Chassis Connector (Console/Stabilizer Harness)
Cab/Chassis Connector to Splice 150 (Engine Harness)
Wire No. Gauge Color From - Function - To
