Configuration Effective controller parameters with three-point controller
CFunc =
2-Punkt
Popt Parameter set for self-tun ing (only with CONTR+) 1...6
W0 1) Lower limit for Weff -29 999 ...999 999
W100 1) Upper limit for Weff -29 999 ...999 999
W2 1) Additional -29 999 ...999 999
Grw+ 2) gradient plus off / 0,001 ... 999 999
Grw- 2) gradient minus off / 0,001 ... 999 999
Grw2 2) gradient for W2 off / 0,001 ... 999 999
N0 Zero offset (effective only with CType=ratio controller) -29 999 ...999 999
a Factor a (effective only with CType=3-element control) -9,99 ... 99,99
Xsh1 3) Neutral zone (Xw > 0) 0,0 ... 1000 [%]
Xsh2 3) Neutral zone (Xw < 0) 0,0 ... 1000 [%]
Y2 Additional positioning value 0 … 100 [%]
Ymin Min. output limiting 0 … 100 [%]
Ymax Max. output limiting 0 … 100 [%]
Y0 Correcting variable working point (start-up corr. variable) 0...100 [%]
YOptm Positioning value during process at rest 0...100 [%]
dYopt Step height during self-tuning 5...100 [%]
Xp1(1...6) 3) 5) Proportional band 1 0,1 … 999,9 [%]
Xp2(1...6) 3) 5) Proportional band 2 0,1 … 999,9 [%]
Tn1(1...6) 5) Integral action time 0 … 999 999 [s]
Tv1(1...6) 5) Derivative action time 0 … 999 999 [s]
Tp1(1...6) 5) Cycle time heating 0,4 … 999,9 [s]
Tp2(1...6) 5) Cycle time cooling 0,4 … 999,9 [s]
Titel Title of controller page (only display) 16 characters
Einh.X Unit of process value (only display) 6 characters
W int 1) Internal after transmission of the engineering to KS 98-1 -29 999 ...999 999
A/H Status of controller after transmission of the engineering to KS 98-1 0 or 1
1) The values are specified in the process value unit - e.g. [°C, °F, bar, %, etc.]
2) The rate of change must be specified in units/minute (e.g. °C/min) r see gradient control page 261.
3) % specifications are related to measuring range
Xn100 - Xn0. There is no relation to values W0 and W100.
4) As default, value Ymin is set to 0. In this case, output Y1 cannot switch!
5) (
1...6) refers to the six parameter sets of CONTR+ (e.g. Xp1, Xp2, Xp3...Xp6).
