158 Airborne Enterprise CLI Reference Manual
io-dir
Command io-dir
Arguments f | g [in | out]
Security
Level
2 (data)
Device Type All
Default f in | g in
Description Sets the direction of the indicated GPIO port dynamically without restarting the module.
The command requires two parameters the first identifies the GPIO port and bit to be configured the
second determines the default direction of the port. The command acts upon all GPIO in the identified
port. For example:
io-dir f1 out : Sets the f port first bit to be an output
io-dir g7 in : Sets the g port seventh bit to be input
The effects of this command are temporary and will not be persistent across a restart. If the port and
bit direction are required to persist across a power cycle or restart use the io-dir-f and io-dir-g
commands.
The Port can be read or written to using the io-read and io-write commands.
Port assignment and exceptions:
f0 Read or Write (POST output) g0 Read or Write
f1 Read or Write g1 Read or Write
f2 Read or Write (RF_LINK output) g2 Read or Write
f3 Read or Write (WLN_CFG output) g3 N/A
f4 Read or Write g4 N/A
f5 Read or Write g5 N/A
f6 Read or Write (LED_CON output) g6 Read or Write
f7 Read or Write g7 Read or Write
When the LED signal has not been disabled those bits indicated as LED Outputs can only be read in
order to determine the state of the LED output (See WLNN DP500 Family Databook for details). To
disable the LED‟s use one of the following commands post-led, rf-link-led, wln-cfg-led and
conn-led
.
Any attempt to set an unavailable port or configure a port to an illegal state will be ignored.
