700
1
1
.3 T
e
c
hnical Inf
o
rm
ation
TURN PLUS – Sequential programming with
interactive graphics Sequential programming for individual machining steps with:
„ Automatic tool selection
„ Automatic turret assignment
„ Automatic calculation of cutting data
„ Automatic generation of machining sequence in all working planes
(also for C-axis machining (with option 1.1) and Y-axis machining)
„ Automatic cutting limitation through chucking equipment
„ Automatic generation of work blocks for rechucking with machine-
specific expert program (with option 1.2, full-surface machining)
„ Automatic generation of work blocks for rear-side machining (with
option 1.2, full-surface machining)
„ DIN PLUS program generation
TURN PLUS – Automatic sequential
programming Automatic working plan generation with:
„ Automatic DIN PLUS program generation (option)
„ Automatic NC program generation for the rotary axis, C axis, Y axis
and for opposing spindles
„ Automatic tool selection
„ Automatic turret assignment
„ Automatic generation of the machining sequence in all working
planes
„ Automatic cutting limitation through clamping devices
„ Automatic rechucking with machine-specific expert program for rear-
side machining
„ Automatic generation of work blocks for rechucking and for the
second setup
Measuring
In the machine (option 2) For setting up tools and measuring workpieces in the “Manual” and
“Automatic” modes using a touch probe
On external inspection stations (option 3) Transfer of results from an external measuring device for processing the
measured data in the “automatic” operating mode:
„ Up to 16 measuring points
„ RS-232-C/V.24 data interface
„ Communications protocol: 3964-R
Standard functions CNC PILOT 4290
