4-6
MAXQ Family User’s Guide
4.9 Watchdog Control Register (WDCN, 8h[Fh])
Initialization: Bits 5, 4, 3 and 0 are cleared to 0 on all forms of reset; for others, see individual bit descriptions.
Access: Unrestricted direct read/write access.
BIT FUNCTION
WDCN.0 (RWT)
Reset Watchdog Timer. Setting this bit to 1 resets the watchdog timer count. If watchdog interrupt and/or reset modes are
enabled, the software must set this bit to 1 before the watchdog timer elapses to prevent an interrupt or reset from occurring.
This bit always returns 0 when read.
WDCN.1 (EWT)
Enable Watchdog Timer Reset. If this bit is set to 1 when the watchdog timer elapses, the watchdog resets the processor 512
system clock cycles later unless action is taken to disable the reset event. Clearing this bit to 0 prevents a watchdog reset from
occurring but does not stop the watchdog timer or prevent watchdog interrupts from occurring if EWDI = 1. If EWT = 0 and EWDI
= 0, the watchdog timer will be stopped. If the watchdog timer is stopped (EWT = 0 and EWDI = 0), setting the EWT bit will reset
the watchdog interval and reset counter, and enable the watchdog timer. This bit is cleared on Power-on reset and is unaffected
by other forms of reset.
WDCN.2 (WTRF)
Watchdog Timer Reset Flag. This bit is set to 1 when the watchdog resets the processor. Software can check this bit following a
reset to determine if the watchdog was the source of the reset. Setting this bit to 1 in software will not cause a watchdog reset.
This bit is cleared by Power-on reset only and is unaffected by other forms of reset. It should also be cleared by software following
any reset so that the source of the next reset can be correctly determined by software. This bit is only set to 1 when a watchdog
reset actually occurs, so if EWT is cleared to 0 when the watchdog timer elapses, this bit will not be set.
WDCN.3 (WDIF)
Watchdog Interrupt Flag. This bit will be set to 1 when the watchdog timer interval has elapsed or can be set to 1 by user
software. When WDIF = 1, an interrupt request will occur if the watchdog interrupt has been enabled (EWDI = 1) and not
otherwise masked or prevented by an interrupt already in service (i.e., IGE = 1, IMS = 1, and INS = 0 must be true for the interrupt
to occur). This bit should be cleared by software before exiting the interrupt service routine to avoid repeated interrupts.
Furthermore, if the watchdog reset has been enabled (EWT = 1), a reset is scheduled to occur 512 system clock cycles following
setting of the WDIF bit.
Watchdog Timer Mode Select Bit 0; Watchdog Timer Mode Select Bit 1. These bits determine the watchdog interval or the length
of time between resetting of watchdog timer and the watchdog generated interrupt in terms of system clocks. Modifying the
watchdog interval via the WD1:0 bits will automatically reset the watchdog timer unless the 512 system clock reset counter is
already in progress, in which case, changing the WD1:0 bits will not effect the Watchdog timer or reset counter.
WD1 WD0 CLOCKS UNTIL INTERRUPT CLOCKS UNTIL RESET
0 0 2 12 2 12 + 512
0 1 2 15 2 15 + 512
1 0 2 18 2 18 + 512
WDCN.4 (WD0);
WDCN.5 (WD1)
1 1 2 21 2 21 + 512
WDCN.6 (EWDI)
Watchdog Interrupt Enable. If this bit is set to 1, an interrupt request can be generated when the WDIF bit is set to 1 by any
means. If this bit is cleared to 0, no interrupt will occur when WDIF is set to 1, however, it does not stop the watchdog timer or
prevent watchdog resets from occurring if EWT = 1. If EWT = 0 and EWDI = 0, the watchdog timer will be stopped. If the
watchdog timer is stopped (EWT = 0 and EWDI = 0), setting the EWDI bit will reset the watchdog interval and reset counter, and
enable the watchdog timer. This bit is cleared to 0 by power-on reset and is unaffected by other forms of reset.
WDCN.7 (POR)
Power-On Reset Flag. This bit is set to 1 whenever a power-on/brownout reset occurs. It is unaffected by other forms of reset. This
bit can be checked by software following a reset to determine if a power-on/brownout reset occurred. It should always be cleared
by software following a reset to ensure that the sources of following resets can be determined correctly.
