3-21
Table 3-6. System Register Bit Reset Values
Note: Bits marked ‘s’ are static across some or all resets.
BIT POSITION
REGISTER
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
AP 0 0 0 0 0 0 0 0
APC 0 0 0 0 0 0 0 0
PSF 1 0 0 0 0 0 0 0
IC 0 0 0 0 0 0 0 0
IMR 0 0 0 0 0 0 0 0
SC 1 0 0 0 0 0 s 0
IIR 0 0 0 0 0 0 0 0
CKCN s s s 0 0 0 0 0
WDCN s s 0 0 0 s s 0
A[n]
MAXQ10
0 0 0 0 0 0 0 0
A[n]
MAXQ20
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
PFX 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
IP 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SP 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1
IV 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
LC[0] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
LC[1] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
OFFS 0 0 0 0 0 0 0 0
DPC
MAXQ10
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
DPC
MAXQ20
0 0 0 0 0 0 0 0 0 0 0 1 1 1 0 0
GR 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GRL 0 0 0 0 0 0 0 0
BP 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GRS 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GRH 0 0 0 0 0 0 0 0
GRXL 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
FP 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
DP[0] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
DP[1] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
