2-5

2.2 Register Space

The MAXQ architecture provides a total of 16 register modules. Each of these modules contains 32 registers. The first eight registers

in each module may be read from or written to in a single cycle; the second eight registers may be read from in a single cycle and writ-

ten to in two cycles (by using the prefix register PFX); the last sixteen registers may be read or written in two cycles (always requiring

use of the prefix register PFX).

Registers may be either 8 or 16 bits in length. Within a register, any number of bits can be implemented; bits not implemented are fixed

at zero. Data transfers between registers of different sizes are handled as shown in Table 2-1.

• If the source and destination registers are both 8 bits wide, data is transferred bit to bit accordingly.

• If the source register is 8 bits wide and the destination register is 16 bits wide, the data from the source register is transferred into

the lower 8 bits of the destination register. The upper 8 bits of the destination register are set to the current value of the prefix regis-

ter; this value is normally zero, but it can be set to a different value by the previous instruction if needed. The prefix register reverts

back to zero after one cycle, so this must be done by the instruction immediately before the one that will be using the value.

• If the source register is 16 bits wide and the destination register is 8 bits wide, the lower 8 bits of the source are transferred to the

destination register.

• If both registers are 16 bits wide, data is copied bit to bit.

Table 2-1. Register-to-Register Transfer Operations

The above rules apply to all data movements between defined registers. Data transfer to/from undefined register locations has the fol-

lowing behavior:

• If the destination is an undefined register, the MOVE is a dummy operation but may trigger an underlying operation according to the

source register (e.g., @DP[n]--).

• If the destination is a defined register and the source is undefined, the source data for the transfer will depend upon the source module

width. If the source is from a module containing 8-bit or 8-bit and 16-bit source registers, the source data will be equal to the prefix data

concatenated with 00h. If the source is from a module containing only 16-bit source registers, 0000h source data is used for the transfer.

The 16 available register modules are broken up into two different groups. The low six modules (specifiers 0h through 5h) are known

as the Peripheral Register modules, while the high 10 modules (specifiers 6h to Fh) are known as the System Register modules. These

groupings are descriptive only, as there is no difference between accessing the two register groups from a programming perspective.

The System Registers define basic functionality that remains the same across all products based on the MAXQ architecture. This

includes all register locations that are used to implement higher level op codes as well as the following common system features.

• ALU (MAXQ10: 8 bit; MAXQ20: 16 bit) and associated status flags (zero, equals, carry, sign, overflow)

• Eight working accumulator registers (MAXQ10: 8 bit width; MAXQ20: 16 bit width), along with associated control registers

• Instruction pointer

• Registers for interrupt control, handling, and identification

• Auto-decrementing Loop Counters for fast, compact looping

• Two Data Pointer registers and a Frame Pointer for data memory access

The Peripheral Registers define additional functionality that may be included by different products based on the MAXQ architecture. This

functionality is broken up into discrete modules so that only the features that are required for a given product need to be included. Since

the Peripheral Registers add functionality outside of the common MAXQ system architecture, they are not used to implement op codes.

DESTINATION SET TO VALUE

SOURCE REGISTER SIZE

(BITS)

DESTINATION REGISTER

SIZE (BITS)

PREFIX SET?

HIGH 8 BITS

LOW 8 BITS

8

8

Source [7:0]

8

16

No

00h

Source [7:0]

8

16

Yes

Prefix [7:0]

Source [7:0]

16

8

Source [7:0]

16

16

No

Source [15:8]

Source [7:0]
