12-7
MAXQ Family User’s Guide
12.5.5 Multiplier Accumulator 1 Register (MC1)
Bits 15 to 0: Multiplier Accumulator 1 Register (MC1.[15:0]). The MC1 register represents bytes 3 and 2 of the accumulator regis-
ter. The 48-bit accumulator is formed by MC2, MC1, and MC0.
12.5.6 Multiplier Accumulator 0 Register (MC0)
Bits 15 to 0: Multiplier Accumulator 0 Register (MC0.[15:0]). The MC0 register represents the two least significant bytes of the accu-
mulator register. The 48-bit accumulator is formed by MC2, MC1, and MC0.
Bit #
15
14
13
12
11
10
9
8
Name
MC1.15
MC1.14
MC1.13
MC1.12
MC1.11
MC1.10
MC1.9
MC1.8
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
Bit #
7
6
5
4
3
2
1
0
Name
MC1.7
MC1.6
MC1.5
MC1.4
MC1.3
MC1.2
MC1.1
MC1.0
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
r = read, w = write
Bit #
15
14
13
12
11
10
9
8
Name
MC0.15
MC0.14
MC0.13
MC0.12
MC0.11
MC0.10
MC0.9
MC0.8
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
Bit #
7
6
5
4
3
2
1
0
Name
MC0.7
MC0.6
MC0.5
MC0.4
MC0.3
MC0.2
MC0.1
MC0.0
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
r = read, w = write
Maxim Integrated
