Rockwell Automation Publication IASIMP-QS034A-EN-P - October 2012 87
GuardLogix Configuration
Chapter 4
GuardLogix Controller and Network Configuration
In this section you will create a new GuardLogix project file and configure the EtherNet/IP communications.
Create a New Project File
Throughout this section the controller and network configuration procedures are written specifically for a
1756-L6
x or 1756-L6xS ControlLogix controller. If you are integrating Kinetix motion into your project, we
recommend that you select a 1756-L7
xS for your system. Steps for other Logix controller and communication
modules are similar.
1. From the Start menu, launch RSLogix 5000 software.
2. Click New Project.
The New Controller dialog box
opens.
IMPORTANT If you are creating a new project and have not configured your personal computer communication or controller hardware,
see Appendix D .
