12 Rockwell Automation Publication IASIMP-QS034A-EN-P - October 2012
Preface
Conventions
This manual uses the following conventions.
Required Software
To complete this quick start, the following software is required.
Convention Meaning Example
CNC
Used as an abbreviation for Computer Numeric Control. In this Toolkit,
The GuardLogix PLC communicates to the FANUC CNC by using the
EtherNet/IP communication protocol.
GuardLogix PLC to FANUC CNC EtherNet/IP
configuration.
Click
Click the left mouse button once (assumes cursor is positioned on object
or selection). Click button to initiate action.
Click Browse.
Double-click
Click the left mouse button twice in quick succession (assumes cursor is
positioned on object or selection).
Double-click the H1 icon.
Right-click
Click the right mouse button once (assumes cursor is positioned on
object or selection).
Right-click the Fieldbus Networks icon.
Drag and drop
Click and hold the left mouse button on an object, move the cursor to
where you want to move the object, and release the mouse button. Drag and drop the desired block into the Strategy
dialog box.
Select Click to highlight a menu item or list choice. From the pull-down menu, choose H1-1.
Check/uncheck Click to select a checkbox option.
Check Consider Case if you want to conduct a
case-sensitive search.
>
Shows nested menu selections as menu name followed by menu
selection.
Click File >Page Setup>Options.
Expand Click the + to the left of a given item /folder to show its contents. In the H1-1 dialog box, expand FFLD.
Enter Used when you can type from the keyboard or choose from a list. Enter the catalog number of the product.
Type Used when the only option is to type from the keyboard. Type the catalog number of the product.
Press
Press a specific button on the PanelView™ terminal or other component
with touch-screen technology.
Press Axis Control.
Rockwell Automation Software Cat. No. Version Required For
RSLogix™ 5000
• ControlFLASH™
• BOOTP/DHCP utility (EtherNet/IP network)
• RSLinx® Classic
9324-RLD300RNE 20.00 or later
All ControlLogix®/GuardLogix PLC
applications
FactoryTalk View Studio for Machine Edition
• FactoryTalk Services
• RSLinx Enterprise
• RSLinx Classic
9701-VWSTMENE 6.00 or later PanelView Plus terminals
FANUC III for PMC Development
(Microsoft Windows)
A08B-9210-J505 6.80 or later FANUC CNC applications
CNC Machining Accelerator Toolkit DVD IASIMP-SP018 N/A
CAD files, wiring diagrams,
application files, and other
support information
