Rockwell Automation Publication IASIMP-QS034A-EN-P - October 2012
47
Chapter
3
FANUC CNC Configuration
In this chapter you initially configure your FANUC 30i-B, 31i-B, 32i-B, or 35i-B CNC, set up the CNC
communication, and create a new project file for your CNC application. The intent is to provide a quick setup
for an EtherNet/IP connection between a Rockwell Automation ControlLogix/GuardLogix PLC and a
FANUC 30i-B, 31i-B, 32i-B, or 35i-B CNC.
The overall CNC configuration and parameterization is not being addressed by this quick start, and is the
responsibility of the machine tool builder.
Before You Begin
• Complete your system architecture and hardware selection (refer to Chapter 1 ).
• Complete your system layout and wiring (refer to Chapter 2 ).
What You Need
• The CNC Machining Accelerator Toolkit DVD, publication IASIMP-SP018 . For a copy of the DVD,
contact your local Rockwell Automation distributor or sales representative
• FANUC LADDER III software, version 6.8 or later
• USB flash drive
• FANUC Series 30i/31i/32i/35i –MODEL B, EtherNet/IP Adapter function, publication
[email protected]
• FANUC Series 30i/31i/32i/35i -MODEL B, FANUC Power Motion i -MODEL A EtherNet/IP Scanner
function, publication [email protected]
