Appendix B
Logic Module Customization
Tag and Logic Modification Recommendations
This table contains some of the common modifications to consider for the state machine. The modifications and
corresponding recommended actions are meant to highlight the more significant updates that are needed.
Additional updates may also be necessary.
Modification Description Recommended Actions
State Names
Simple change to the state name. The number of states and
relationship between states remain unaltered.
Example: Change RUNNING state to PRODUCING.
• Modify the UDT_MachState data type.
• Update the corresponding MachineSTATE_Add-On
Instruction embedded state name. (1)
• Update the HMI file as needed. (2)
(1) Refer to State Display Tag Modifications, on page 247 , for more information.
(2) Refer to Chapter 5 , on page 147 , for more information on the HMI terminal layout and function.
Command Names
Simple change to the command name. Their intended
function remains unaltered.
Example: Change RESET command to INITIALIZE. • Modify the UDT_MachCmd data type.
• Update the HMI file as needed. (2)
Mode Names
Simple change to the mode name. The number of modes and
their intended function remain unaltered.
Example: Change OPERATOR mode to MANUAL.
• Modify the UDT_MachMode data type.
• Update the HMI file as needed. (2)
Add/Remove States
Adding additional states or removing states. The operation of
the state machine will change to accommodate an increase
or decrease in states.
Example: Add a new state called PAUSED.
• Modify the UDT_MachState data type.
• Modify the machine module monitor and control routines
as needed.
• If necessary, add/remove commands to support the
changes in the states. Refer to Add/Remove Commands
modification.
• If new states were added, then update the corresponding
MachineSTATE_Add-On Instruction embedded state
name.
• Update the HMI file as needed. (2)
Add/Remove Commands
Adding additional commands or removing commands.
Typically, increases or decreases in commands are required
to support corresponding changes (+/-) with states.
Example: Add a new command called PAUSE to support a
new state called PAUSED.
• Modify the UDT_MachCmd data type.
• Modify the machine module monitor and control routines
as needed.
• Modify the application and device modules monitor and
control routines as needed. Typically, changes in
commands require changes in the module status
(UDT_AppStatus and UDT_ModuleStatus). For example, if
you add a new command called PAUSE, then you must add
a new status response from the modules called Paused.
• Update the HMI file as needed. (2)
Add/Remove Modes
Adding additional modes or removing modes.
Example: Add a new mode called THREAD.
• Modify the UDT_MachMode data type.
• Modify the machine module monitor and control routines
as needed.
• Modify the application and device modules monitor and
control routines as needed.
• Update the HMI file as needed. (2)
State-to-State
Relationships
Changing the conditions that enable transitions between
states.
Example: Update logic to transition from STOPPED directly to
STARTING, bypassing IDLE.
• Modify the machine module monitor and control routines
as needed.
• Modify the application and device modules monitor and
control routines as needed.
• Update the HMI file as needed. (2)
