Chapter
7
System Application Guide
This chapter guides you through the pre-configured FactoryTalk View Machine Edition application faceplates
providing you with an understanding of the status, control, and diagnostic operation of the faceplate displays.
Before You Begin
•
Complete your system architecture and hardware selection (refer to
).
•
Complete your system layout and wiring (refer to
•
Complete your FANUC CNC Configuration (refer to
).
•
Complete your logic configuration (refer to
).
•
Complete your FactoryTalk View Machine Edition configuration (refer to
)
•
Complete your system commissioning (refer to
What You Need
•
The CNC Machining Accelerator Toolkit DVD, publication
. For a copy of the DVD,
contact your local Rockwell Automation distributor or sales representative.
•
Hardware installation and wiring complete with power applied.
•
Logix application file downloaded to the ControlLogix or CompactLogix controller. Controller set to run.
•
FactoryTalk View ME runtime application file downloaded to the PanelView Plus terminal. Run
Application activated on terminal.
