Rockwell Automation IASIMP Computer Numerical Control (CNC) Machining Accelerator Toolkit Quick Start User Manual
Page 218
218
Rockwell Automation Publication IASIMP-QS034A-EN-P - October 2012
Chapter 7
System Application Guide
Table 8 - Machine Status Indicators
Status Indicator
Color/Value
Description
OK
Green
No machine faults detected.
Faulted
Red
Machine fault detected.
Abort Status
Power Up
Displays additional diagnostic information for machine ABORT condition.
Module Not Ready
Module Fault
Failed to RESET
Failed to START
Failed to STOP
Failed to CLEAR
Ready
Green
Machine is ready to run. By default, the machine is in one of the following states: IDLE, STARTING
or RUNNING
Gray
Machine is not ready to run.
Safe Speed
Green
Safe speed condition is currently active in at least one device module.
Gray
Safe speed condition is not currently active.
State
ABORTING
Displays the current machine state.
ABORTED
CLEARING
RESETTING
IDLE
STARTING
RUNNING
STOPPING
STOPPED
