Rockwell Automation Publication IASIMP-QS034A-EN-P - October 2012

179

FactoryTalk View ME Configuration

Chapter 5

8.

Right-click Display and choose Paste.

9.

Repeat

step 1

step 8

for each CNC module in your application.

Associate Each Button to a Faceplate and Parameter File

1.

Click the copied Goto display button and
from the View menu, choose Object
Explorer.

2.

In the Object Explorer tool, double-click
the Goto display button to open the
Goto Display Button Properties dialog
box.
