Chapter 5
FactoryTalk View ME Configuration
Delete Unused Displays
1. Determine the required faceplates for your application based on the table below.
For the CNC Work Cell example, use these display names:
• PVP1000_AlarmHistory_Faceplate
• PVP1000_EquipmentStatus_Faceplate
• PVP1000_Startup_Faceplate
• PVP1000_StateDiagram_Faceplate
• Fanuc_CNC_Faceplate
• CIPMotion_Faceplate
TIP
Only one faceplate display is required for devices/modules of the same type.
Faceplate Display Name Parameter File Supported Devices/Modules
Supported PanelView Plus
Terminals
CIPMotion_Faceplate CIPMotion_Parameter
Kinetix 6500 drives and PowerFlex 755
drive configured as CIP Motion drive
All
Fanuc_CNC_Faceplate Fanuc_CNC_Parameter Fanuc 30i B-Series CNCs
K300_Faceplate K300_Parameter Kinetix 300 drives
PowerFlex_4_40_400_Faceplate
PF_Parameter
PowerFlex 4, PowerFlex 40,and
PowerFlex 400 drives
PowerFlex_40P_Faceplate PowerFlex 40P drives
PowerFlex_70_700_Faceplate
PowerFlex 70EC and
PowerFlex 700VC drives
PowerFlex_700S_700S2_Faceplate PowerFlex 700S2 drives
PowerFlex_753_755_Faceplate
PowerFlex 753 and
PowerFlex 755 drives
PVP1000_AlarmHistory_Faceplate Not Required
All devices PanelView Plus 700,
PanelView Plus 1000,
PanelView Plus 1250,
(1)
PanelView Plus 1500
(1)
PVP1000_EquipmentStatus_Faceplate EquipmentStatus_Parameter
PVP1000_Startup_Faceplate Startup_Parameter Machine logic module
PVP1000_StateDiagram_Faceplate StateDiagram_Parameter Machine logic module (states)
PVP600_Startup_Faceplate Startup_Parameter Machine logic module
PanelView Plus 400,
PanelView Plus 600
SERCOS_Faceplate SERCOS_Parameter
Kinetix 2000, Kinetix 6000,
Kinetix 6200, Kinetix 7000, and
Ultra™ 3000-SE drives
All
(1) The PanelView Plus 1000 Machine, Alarm History, and Equipment Status faceplate displays are sized at 640x480 (VGA) resolution. If full-sized displays are
desired, open display, select all (objects), group, and resize group. Some text editing for new display size may also be required.
