170

Rockwell Automation Publication IASIMP-QS034A-EN-P - October 2012

Chapter 5

FactoryTalk View ME Configuration

For the CNC Work Cell example, the parameters are edited as follows.

CNC Work Cell Parameter File

Parameter File Configuration

Drill_CNC

#1=::[CLX]

#2=::[CLX]Drill_CNC_FP

Machine_CNC

#1=::[CLX]

#2=::[CLX]Machine_CNC_FP

Gantry_X_Axis

#1=::[CLX]

#2=::[CLX]Gantry_X_Axis_FP

Gantry_Y_Axis

#1=::[CLX]

#2=::[CLX]Gantry_Y_Axis_FP

MachingStatus

#1=::[CLX]Drill_CNC_FP

#2=::[CLX]Machine_CNC_FP

#3=::[CLX]Gantry_X_Axis_FP

#4=::[CLX]Gantry_Y_Axis_FP

#5=::[CLX]Gantry_Y_Axis_FP

#6=::[CLX]Gantry_Y_Axis_FP

#7=::[CLX]Gantry_Y_Axis_FP

#8=::[CLX]Gantry_Y_Axis_FP

#9=::[CLX]Gantry_Y_Axis_FP

Startup

#1=::[CLX]

#2=::[CLX]CNC_Work_Cell

StateDiagram #1=::[CLX]CNC_Work_Cell

The machining status faceplate requires
that parameters are set for all rows #1…9
even if they are not visible. Typically, the
last visible row parameter is entered in
the remaining parameters. For example,
Gantry_Y_Axis_FP parameter entered for
#5...9.

Refer to

Configure Equipment Status

Faceplate Display on page 185

for more

information.
