Chapter 7 motion system application guide – Rockwell Automation IASIMP Computer Numerical Control (CNC) Machining Accelerator Toolkit Quick Start User Manual
Page 3
Rockwell Automation Publication IASIMP-QS034A-EN-P - October 2012
3
Follow this path to complete your CNC machining application.
MOTOR
FIELD SIDE
DRIVE
PROTECTION
POWERFLEX 4
AC DRIVE
MOTOR_01
USER PROTECTED
XXXVAC SUPPLY
MAINS DISCONNECT
PROTECTION
XXAMPS
FILTERED POWER
Chapter 7
Motion System Application Guide
RESETTING
IDLE
(enabled)
STARTING
START
RUNNING
STOPPING
STOP
STOPPED
(disabled)
CLEARING
ABORTED
ABORTING
RESET
ABORT
CLEAR
The machine can go from any state in the shaded box to STOPPING.
The machine can go from any state
in the solid box to ABORTING.
Architecture and Hardware Selection
GuardLogix®
Configuration
FactoryTalk® View ME
Configuration
