3 PANEL AND BASIC OPERATIONS
APS-1102A 3-19
3.4.2 Setting output mode
The APS-1102A provides the eight output modes listed in Table3-7. The output mode cannot be
changed while output is on. Before changing the output mode, set output to off.
Table3-7. Output Mode List
Operation
Mode
Signal Source Mode Output Mode Reference
AC
INT
(internal)
AC-INT “3.4.2 Setting output mode”
EXT
(external)
AC-EXT “4.9 Amplification of External Signal”
ADD
(internal + external)
AC-ADD
“4.10 Adding External Signals and
Internal Signals ”
SYNC
(external sync)
AC-SYNC
“4.7 Synchronize the Output with
External Signal ”
AC+DC
INT
(internal)
AC+DC-INT “4.1 Use as a DC Power Source”
EXT
(external)
AC+DC-EXT “4.9 Amplification of External Signal”
ADD
(internal + external)
AC+DC-ADD
“4.10 Adding External Signals and
Internal Signals ”
SYNC
(external sync)
AC+DC-SYNC
“4.7 Synchronize the Output with
External Signal ”
Setting to AC-INT mode is described below as an example.
